ABB DSQC2360 Servo Driver Control Board

1. Product Overview

The ABB DSQC2360 Servo Driver Control Board is a core control unit in ABB industrial robots and automation systems, designed for servo motor drive and motion control. It uses a high-performance processor to execute real-time motion control algorithms, managing motor speed, position, and torque for precise robotic and automation applications. Multi-channel I/O interfaces and communication buses ensure reliable connection with the control system and external devices.

2. Technical Specifications

General

• Model: DSQC2360

• Type: Servo Driver Control Board

• Manufacturer: ABB

• Installation: Slot-mounted in drive control cabinet or modular drive unit

Electrical

• Operating Voltage: 24V DC (logic control)

• Power Consumption: 30–50W (depending on system load)

• I/O Interfaces:

  • Multi-channel digital I/O

  • Multi-channel analog I/O

  • Communication: ABB industrial bus and standard industrial protocols

• Drive Signals: Pulse/Direction, PWM, or dedicated servo protocol

• Isolation: Logic circuitry isolated from power stage for system stability

Performance

• Controller: Industrial high-performance microprocessor

• Response Time: Real-time, suitable for high-speed motion

• Supported Functions:

  • Closed-loop control of servo motor speed, position, and torque

  • Motor overload protection and status monitoring

  • Communication with upper-level controller or robot control unit

• Storage: Built-in non-volatile memory for parameters and configuration

Environmental

• Operating Temperature: 0°C to +55°C

• Storage Temperature: –25°C to +70°C

• Humidity: 5%–95% non-condensing

• Protection Class: IP20

• Vibration Resistance: Industrial-grade, suitable for robot drive cabinet environments

3. Features & Advantages

1. High-precision servo control with real-time closed-loop operation.

2. Multi-channel I/O support for digital, analog, and communication signals.

3. Industrial-grade reliability and strong interference immunity.

4. Modular design for easy replacement, maintenance, and system upgrade.

5. Built-in protection for overload, over-temperature, and over-voltage.

6. High compatibility with ABB industrial robots, servo drives, and control systems.

4. Application Areas

• ABB industrial robot servo drive systems

• Automated production line motion control

• Servo motor speed, position, and torque control

• Industrial robotic arms and material handling systems

• CNC machines, machining centers, and automated assembly lines

• Motor drive control cabinets and automation equipment control units

5. Precautions & Maintenance

1. Disconnect power before installation or maintenance.

2. Ensure supply voltage and wiring comply with board specifications.

3. Avoid installation in high humidity, high temperature, or corrosive environments.

4. Regularly check slots, terminals, and cooling conditions.

5. Avoid strong vibrations or mechanical shocks.

6. Do not exceed current, power, or temperature specifications.

7. Use ABB-compatible drive control cabinets and connection interfaces.
