ABB DSQC228 Controller Module

1. Product Overview

The ABB DSQC228 Controller Module is a key processing unit in ABB industrial robot control systems. It manages robot motion control, I/O signal handling, logic processing, and system communication. Featuring a high-performance industrial processor and robust interfaces, it ensures high-speed and precise control while providing diagnostic and fault alarm functions for reliable operation of robots and automated production lines.

2. Technical Specifications

General

• Model: DSQC228

• Type: Controller Module

• Manufacturer: ABB

• Installation: Slot-mounted in robot control cabinet

Electrical

• Supply Voltage: 24V DC

• Power Consumption: <40W (typical)

• I/O Interfaces: Multi-channel for sensors, actuators, and PLC communication

• Communication Protocol: ABB industrial bus and standard industrial protocols

• Isolation: System bus isolated from I/O signals

Performance

• Processor: Industrial-grade high-performance microprocessor

• Response Time: Real-time, supports high-speed robot operations

• Supported Functions:

  • Robot motion control algorithm execution

  • I/O signal acquisition and processing

  • System status monitoring and fault alarms

  • Communication with PLC and upper-level systems

• Built-in Storage: Non-volatile memory for program and parameter storage

Environmental

• Operating Temperature: 0°C to +55°C

• Storage Temperature: –25°C to +70°C

• Humidity: 5%–95% non-condensing

• Protection Class: IP20

• Vibration Resistance: Industrial-grade

3. Features & Advantages

1. High-speed and precise control for robot and automation systems.

2. Multi-functional I/O support for sensors, actuators, and PLC integration.

3. Industrial-grade reliability for continuous operation in harsh environments.

4. Modular design allows quick replacement, upgrades, and maintenance.

5. Real-time system diagnostics and fault alarms enhance maintenance efficiency.

6. High compatibility with ABB robots and automation systems.

4. Application Areas

• ABB industrial robot control cabinets

• Core control units for automated production lines

• Robotic arms and material handling systems

• PLC/DCS signal processing and control

• Automated assembly, welding, and packaging lines

• Factory electrical control cabinets and automation hubs

5. Precautions & Maintenance

1. Disconnect power before installation or maintenance.

2. Ensure supply voltage and wiring comply with module specifications.

3. Avoid installation in high humidity, dust, or corrosive environments.

4. Periodically check slots and terminals for looseness or damage.

5. Avoid strong vibration or mechanical shocks.

6. Ensure proper ventilation to prevent overheating.

7. Use ABB-compatible control cabinets and bus connections.
