ABB DSQC204 YB560103-AE Analog Output Module

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

 1. Product Overview

The ABB DSQC204 YB560103-AE Analog Output Module is a key I/O component in ABB industrial automation and robot control systems, converting digital signals into analog output for actuators or other industrial devices. The module provides high-precision current or voltage output, fast response, and reliable performance, widely used in ABB robots, DCS, and automation systems for precise process control and actuator driving.

2. Main Technical Parameters (Typical)

Output Signal Characteristics

• Model: DSQC204 YB560103-AE

• Output type: Analog output (current/voltage configurable)

• Number of output channels: Typically 4

• Output range: 0–20 mA / 4–20 mA / 0–10 V / ±10 V (system dependent)

• Resolution: 16-bit

• Response time: ≤ 1 ms

• Load capacity: Current output 500 Ω max, voltage output 10 kΩ min

Electrical & Environmental Characteristics

• Supply voltage: 24 V DC

• Operating temperature: 0°C to +55°C

• Relative humidity: 5%–95% (non-condensing)

• Industrial EMI design for high noise immunity

Mechanical & Installation

• Mounting: DIN rail or dedicated module slot

• Dimensions: Compact for easy control cabinet integration

• Weight: approx. 0.5 kg

System Compatibility

• Compatible with ABB robots and automation systems

• Seamless integration with ABB controllers and I/O modules

Standards & Certifications

• Compliant with ABB internal industrial standards

• CE and RoHS certified

3. Advantages and Features

• High-precision output: 16-bit resolution for accurate control

• Fast response: ≤1 ms output response for real-time control

• Modular design: Compact and easy to install and maintain

• High reliability: Industrial-grade design with strong noise immunity

• Flexible signal support: Current or voltage output to suit various devices

• High ABB system compatibility: Easy integration with robots or DCS systems

4. Typical Applications

• Servo control for ABB industrial robots

• Actuator control in automated production lines

• Analog control in process industries (chemical, power, pharmaceutical, food)

• DCS or PLC output control modules

• Precision machinery and assembly equipment

• HVAC, pumps, valves, and other industrial device control

5. Application Notes

• Ensure output type matches actuator requirement (current or voltage)

• Output load should meet module design limits (current ≤500 Ω, voltage ≥10 kΩ)

• Supply voltage must be stable 24 V DC

• Observe anti-static and dust protection during installation

• Periodically check terminals and communication status

• Avoid long-term operation in high temperature or high humidity environments
