ABB DSQC 307 3HAA3573-AJA Mini Backplane Module

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

1. Product Overview

The ABB DSQC 307 (3HAA3573-AJA) is a Mini Backplane Module designed for ABB industrial robot controllers, such as the IRC5 series. It serves as an internal data bus module, providing high-speed, reliable communication between controller units. The compact and robust module is a core component of the robot controller, ensuring stable motion control and I/O data transmission.

2. Technical Specifications

• Model: DSQC 307 / 3HAA3573-AJA

• Type: Mini Backplane Module

• Compatible Controller: ABB IRC5 series

• Function: High-speed internal data bus communication between controller modules

• Mounting: Inserted into controller backplane/internal slot

• Operating Temperature: 0℃ ~ +55℃

• Storage Temperature: -25℃ ~ +70℃

• Power Requirements: Powered by the controller backplane

• Dimensions: Compact module design for easy integration

• Weight: ~150 g

• Protection Degree: IP20

• Communication Interface: High-speed internal bus interface, supporting data transmission between controller units

• Reliability: Industrial-grade design for long-term robot controller operation

3. Key Features & Advantages

1. High reliability — Industrial-grade design ensures stable internal data communication.

2. High-speed data transmission — Supports fast communication between IRC5 controller modules for precise motion control.

3. Modular design — Plug-in, compact module simplifies maintenance, upgrades, and replacement.

4. Compact structure — Saves internal controller space and improves system integration density.

5. Easy installation and maintenance — Plug-in design reduces downtime.

6. Strong compatibility — Specifically designed for ABB IRC5 controllers, ensuring overall system stability.

4. Typical Applications

• Internal data bus communication in ABB IRC5 robot controllers

• Module-to-module communication in industrial robot control systems

• Factory automation robot systems

• Maintenance and upgrade of robot controllers

• High-precision motion control and industrial automation systems

5. Precautions & Recommendations

1. Turn off the controller power before installation or replacement to avoid electrical damage.

2. Insert the module into the designated slot to ensure proper backplane contact.

3. Avoid high temperature, humidity, or corrosive environments.

4. Protect the module from static discharge and mechanical shock during transportation or storage.

5. Installation and maintenance should be performed by qualified personnel.

6. Regularly check module and internal controller connections to ensure long-term stable operation.
