ABB DSQC 249A 3HAA3563-AGA Servo Rectifier Power Supply Board

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

1. Product Overview

The ABB DSQC 249A (3HAA3563-AGA) is a Servo Rectifier Power Supply Board designed for ABB servo drive systems. It converts AC input voltage into stable DC voltage to supply servo drives, ensuring high-precision, responsive operation of servo motors in robots and automation equipment. The DSQC 249A is a core power module in IRC5 series robot controllers and ABB servo systems.

2. Technical Specifications

• Model: DSQC 249A / 3HAA3563-AGA

• Type: Servo Rectifier Power Supply Board

• Compatible System: ABB IRC5 robot controllers and servo drive systems

• Input Voltage: 3×380–480 V AC, 50/60 Hz

• Output Voltage: 310–700 V DC (according to drive requirements)

• Output Power: Matched to servo drive and motor

• Rectification: Three-phase full-wave rectifier

• Efficiency: ≥ 95%

• Operating Temperature: 0℃ ~ +50℃

• Storage Temperature: -25℃ ~ +70℃

• Mounting: Controller internal slot or fixed installation

• Dimensions: Standard board size for controller

• Weight: ~1.5 kg

• Protection Degree: IP20

• Reliability: Industrial-grade design suitable for long-term continuous operation

3. Key Features & Advantages

1. High-efficiency rectification — Provides stable DC voltage for precise servo drive operation.

2. Strong compatibility — Designed for ABB IRC5 controllers and servo systems, ensuring overall system stability.

3. High reliability — Industrial-grade design withstands long-term operation and short-term overload.

4. Compact structure — Fits inside controller space efficiently, supporting high system integration.

5. Easy maintenance — Modular design allows quick replacement and upgrade.

6. Overcurrent and overvoltage protection — Built-in protection safeguards servo motors and drives.

4. Typical Applications

• ABB IRC5 series robot controllers

• Industrial robot servo drive systems

• Automated production line motion control

• Servo motor power supply

• Factory automation and high-precision motion control systems

• Robot and automation equipment maintenance and upgrade

5. Precautions & Recommendations

1. Power off the controller before installation or removal to ensure safety.

2. Confirm that input voltage matches servo drive requirements to avoid damage.

3. Avoid high temperature, high humidity, dust, or corrosive environments.

4. Secure the module firmly to prevent vibration or loose connections.

5. Installation and maintenance should be performed by qualified personnel.

6. Regularly inspect connections and cooling conditions to ensure long-term reliability.
