ABB DSQC 245 Serial Measurement Board

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

1. Product Overview

The ABB DSQC 245 is a Serial Measurement Board designed for ABB industrial robot controllers, such as the IRC5 series, and servo drive systems. It acquires measurement signals from sensors and servo drives via a serial interface and transmits the data to the controller for processing. This enables high-precision robot motion control and process monitoring. The DSQC 245 is a key module for measurement and feedback, ensuring accuracy and reliability of the robot system.

2. Technical Specifications

• Model: DSQC 245

• Type: Serial Measurement Board

• Compatible System: ABB IRC5 robot controllers and servo systems

• Interface Type: Serial communication interface

• Data Rate: High-speed serial data transfer, typically several Mbps

• Signal Types: Sensor measurement signals, servo feedback signals

• Operating Temperature: 0℃ ~ +50℃

• Storage Temperature: -25℃ ~ +70℃

• Mounting: Controller internal slot

• Dimensions: Standard board design

• Weight: ~400 g

• Protection Degree: IP20

• Reliability: Industrial-grade design for long-term continuous operation

• Additional Features: LED indicators, signal fault alarm

3. Key Features & Advantages

1. High-speed data acquisition — Supports serial data transfer at several Mbps for high-frequency measurements.

2. Multi-signal compatibility — Processes various sensor measurement signals and servo feedback signals.

3. Modular design — Plug-in installation for easy maintenance, upgrade, and replacement.

4. Strong compatibility — Designed for ABB IRC5 controllers and servo systems to ensure system stability.

5. High reliability — Industrial-grade design supports long-term operation and transient signal loads.

6. Visual status indicators — LED indicators show module operation and signal status for easy debugging and maintenance.

4. Typical Applications

• Serial data acquisition for ABB IRC5 robot controllers

• Measurement and feedback in industrial robot servo systems

• Sensor data acquisition and monitoring in automated production lines

• High-precision motion control and position feedback systems

• Factory automation and robot system maintenance/upgrades

5. Precautions & Recommendations

1. Power off the controller before installation or removal to ensure safety.

2. Ensure serial interface signal type, voltage, and data rate match module specifications to avoid damage.

3. Avoid high temperature, humidity, dust, or corrosive environments.

4. Secure the module firmly to prevent vibration or poor contact.

5. Installation and maintenance should be performed by qualified personnel.

6. Regularly inspect the module and LED indicators to ensure long-term reliable operation.
