ABB DSQC 224 Modular Input/Output Module

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

1. Product Overview

The ABB DSQC 224 is a Modular Input/Output Module designed for ABB industrial robot controllers, such as the IRC5 series, and automation systems. It manages digital and analog signals to communicate efficiently with sensors, actuators, and servo systems, supporting robot motion control, factory automation, and production line data acquisition. DSQC 224 features high reliability and a modular design, enabling easy system expansion and maintenance.

2. Technical Specifications

• Model: DSQC 224

• Type: Modular Input/Output Module

• Compatible System: ABB IRC5 robot controllers and automation systems

• Digital Inputs: 16 channels, configurable logic levels

• Digital Outputs: 16 channels, capable of driving relay or optocoupler loads

• Analog Inputs: 4–8 channels, 0–10 V or 4–20 mA

• Analog Outputs: 2–4 channels, 0–10 V or 4–20 mA

• Operating Temperature: 0℃ ~ +50℃

• Storage Temperature: -25℃ ~ +70℃

• Mounting: Controller internal slot or DIN rail

• Dimensions: Modular design, suitable for controller expansion

• Weight: ~500 g

• Protection Degree: IP20

• Reliability: Industrial-grade design for long-term continuous operation

• Additional Features: LED indicators for I/O status, supports hot swapping

3. Key Features & Advantages

1. Modular design — Supports plug-in installation for easy system expansion, upgrade, and maintenance.

2. Multi-signal compatibility — Provides digital and analog I/O interfaces with flexible configuration.

3. High reliability — Industrial-grade design supports long-term operation and high-frequency signal processing.

4. Fast response — Suitable for high-precision automation control and real-time data acquisition.

5. Visual status indicators — LED indicators show input/output channel status for easy debugging and troubleshooting.

6. Strong compatibility — Fully compatible with ABB IRC5 controllers and automation systems for stable operation.

4. Typical Applications

• I/O expansion for ABB IRC5 robot controllers

• Interfaces for sensors and actuators in automated production lines

• Motion control and status monitoring for industrial robots

• Input/output management in high-precision servo systems

• Factory automation and robot system maintenance/upgrades

5. Precautions & Recommendations

1. Power off the controller before installation or removal to ensure safety.

2. Ensure input/output signal type, voltage, and current match module specifications to avoid damage.

3. Avoid high temperature, humidity, dust, or corrosive environments.

4. Secure the module firmly to prevent vibration or poor contact.

5. Installation and maintenance should be performed by qualified personnel.

6. Regularly inspect the module and LED indicators to ensure long-term reliable operation.
