ABB DSQC 237 Robot Circuit Board

• • • 1. Product Overview

      The ABB DSQC 237 Robot Circuit Board is a core module in ABB industrial robot control systems, responsible for motion control, sensor signal processing, and drive interface management. It handles logic processing, I/O management, and high-speed communication with other control modules, providing precise and reliable robot motion control and feedback.

      Designed with industrial-grade reliability, the DSQC 237 offers high noise immunity and long-term stability, suitable for continuous operation in industrial automation environments.

      ---

      2. Technical Specifications

      General

      • Model: DSQC 237

      • Type: Robot Circuit Board

      • Compatible Systems: ABB S4 / S4C / S4C+ series robot controllers

      • Function: Robot motion control, I/O management, sensor signal processing

      Electrical Characteristics

      • Operating Voltage: 24 V DC / 5 V DC (supplied by controller)

      • Signal Interface: Digital I/O, Analog I/O

      • Communication: High-speed internal control bus

      • Response Time: < 5 ms

      • Protection: Overvoltage, short-circuit, reverse polarity

      Mechanical & Environmental

      • Mounting: Rack-mounted board

      • PCB: Industrial-grade multilayer, heat and vibration resistant

      • Operating Temperature: 0°C to +55°C

      • Storage Temperature: –25°C to +70°C

      • Humidity: 5%–95%, non-condensing

      • Protection Class: IP20

      Dimensions & Weight

      • Dimensions (L×W×H): ~220 × 120 × 30 mm

      • Weight: ~0.5 kg

      ---

      3. Features & Advantages

      • High-speed real-time control for motion and I/O signals

      • Industrial-grade reliability: vibration and heat resistant

      • Multi-functional: manages digital/analog signals, sensor inputs, and drive interfaces

      • Modular design for easy installation and maintenance

      • Built-in protection: overvoltage, short-circuit, and reverse polarity

      • Fully compatible with ABB S4/S4C/S4C+ controllers

      ---

      4. Application Areas

      • ABB industrial robot control systems

      • Automated production line motion control

      • Welding, handling, and assembly robots

      • CNC machines and external drive interfaces

      • High-precision automation equipment

      • Robot system monitoring and fault diagnostics

      ---

      5. Precautions



      • Disconnect controller power before installation or removal.

      • Use ESD protection to prevent static damage.

      • Avoid high humidity, dust, and corrosive environments.

      • Ensure connectors and terminals are secure to prevent poor contact.

      • Do not modify or repair internal components.

      • Regularly inspect the board and connectors to ensure stable operation.
