ABB 3BHB002751R0102 Main Circuit Interface Board

• • 1. Product Overview

    The ABB 3BHB002751R0102 Main Circuit Interface Board is a core module used in ABB industrial automation and robot systems for the transmission and management of main circuit signals. It provides reliable interfaces between controllers, drives, and external electrical equipment, ensuring safe and stable main circuit operation.

    The board features industrial-grade design with high noise immunity and reliability, suitable for long-term continuous operation.

    ---

    2. Technical Specifications

    General

    • Model: 3BHB002751R0102

    • Type: Main Circuit Interface Board

    • Compatible Systems: ABB industrial robot controllers and automation systems

    • Function: Main circuit signal isolation, interface, distribution, and protection

    Electrical Characteristics

    • Operating Voltage: 24 V DC / 48 V DC (depending on system)

    • I/O Type: Digital signals, control signals

    • Max Current: System-dependent, low-power design typical

    • Isolation: Opto-isolated or electrical isolation

    • Response Time: < 5 ms

    • Protection: Overvoltage, short-circuit, reverse polarity

    Interface & Structure

    • Connection: Multi-pin terminal or plug-in connector

    • Communication: Internal controller bus

    • Mounting: Rack-mounted or panel-fixed

    • PCB: Industrial-grade multilayer board, heat and vibration resistant

    Environmental Conditions

    • Operating Temperature: 0°C to +55°C

    • Storage Temperature: –25°C to +70°C

    • Humidity: 5%–95%, non-condensing

    • Protection Class: IP20

    • Vibration/Shock: Industrial standard

    ---

    3. Features & Advantages

    • Reliable main circuit interface for controllers, drives, and external devices

    • High noise immunity with opto-isolated design

    • Fast response for real-time control of robots and automation equipment

    • Industrial-grade construction for long-term reliability

    • Modular structure for easy installation and maintenance

    • Built-in short-circuit, overvoltage, and reverse polarity protection

    ---

    4. Application Areas

    • ABB industrial robot main circuit interface and signal management

    • Automated production line main circuit control

    • Industrial motor drive systems

    • CNC systems and machining center interface

    • Automation assembly, welding, and material handling control

    • High-reliability industrial control environments

    ---

    5. Precautions



    • Disconnect controller and system power before installation or removal.

    • Ensure wiring complies with rated voltage and current to prevent overload.

    • Avoid routing cables parallel to high-power lines to reduce interference.

    • Use ESD protection when plugging/unplugging the module.

    • Install the module in a dry, ventilated, corrosion-free control cabinet.

    • Regularly inspect connectors and interfaces to ensure good contact.

    • Do not modify internal circuitry or components of the module.
