ABB DSQC 104 Resolver Board

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

1. Product Overview

The ABB DSQC 104 is a Resolver Board used in ABB industrial robot controllers, such as the IRC5 series. It receives and processes resolver signals from servo motors to provide high-precision closed-loop feedback on motor position, angle, and speed. The module is a critical part of the robot servo control system, ensuring precise motion of joints and end-effectors. DSQC 104 provides reliable signal acquisition and conversion, delivering accurate positioning information for multi-axis robot systems.

2. Technical Specifications

• Model: DSQC 104

• Type: Resolver Board

• Compatible System: ABB IRC5 robot controllers

• Function: Receives servo motor resolver signals for position, angle, and speed feedback

• Input Type: Resolver signals (sine/cosine signals)

• Output Type: Digitized position and speed signals for closed-loop control

• Interface Type: Controller backplane interface

• Operating Temperature: 0℃ ~ +50℃

• Storage Temperature: -25℃ ~ +70℃

• Mounting: Controller internal slot

• Dimensions: Modular board design

• Weight: ~400 g

• Protection Degree: IP20

• Reliability: Industrial-grade design for long-term stable operation

• Additional Features: LED status indicators, fault alarms

3. Key Features & Advantages

1. High-precision signal processing — Accurately captures resolver signals for servo motor position, angle, and speed closed-loop feedback.

2. High-speed response — Real-time processing of multi-axis resolver signals improves robot control accuracy and responsiveness.

3. Modular design — Plug-in installation allows easy maintenance and replacement.

4. Industrial-grade reliability — Supports long-term continuous operation and transient load variations.

5. Strong compatibility — Fully compatible with ABB IRC5 controllers and servo drive modules for stable operation.

6. Visual status indicators — LED indicators display board status and fault information for easy debugging and maintenance.

4. Typical Applications

• Servo control systems for ABB IRC5 robot controllers

• Precise joint position and angle control in industrial robots

• Closed-loop feedback for servo motors in automated production lines

• Multi-axis robot motion control and high-precision positioning

• Factory automation and robot system maintenance/upgrades

5. Precautions & Recommendations

1. Power off the controller before installing or removing the resolver board to ensure safety.

2. Ensure connected resolver signal types are compatible with the board to avoid damage.

3. Avoid high temperature, humidity, dust, or corrosive environments.

4. Secure the board firmly to prevent vibration or poor contact.

5. Installation and maintenance should be performed by qualified personnel.

6. Regularly check LED indicators and board temperature to ensure long-term reliable operation.

The structure and details of the product：
