ABB DSIH700 57350001-AR/6 Industrial HMI Input/Output Module

1. Key Parameters

• Product Model: DSIH700 57350001-AR/6
• Product Series: ABB S800 I/O Integrated HMI I/O Modules (Operator Interaction + Localized Control)
• Core Function: Provides operator interaction (key input, display visualization); enables localized I/O control (digital/analog signal processing); communicates with S800 controllers via backplane; enforces multi-level user permissions; supports alarm monitoring and acknowledgment
• HMI & Input Specifications:

  Parameter	Details	Performance Metrics
  Display Panel	- Type: Monochrome LCD (4.3 inches, 320×240 pixels) - Backlight: LED (dimmable, 50,000-hour lifespan) - Viewing Angle: 120° horizontal / 100° vertical (readable in industrial lighting) - Contrast: Adjustable via front keys	Compact display ensures clear visibility of process data (e.g., sensor values, alarm status) in space-constrained cabinets; long backlight life reduces maintenance
  Input Interface	- Key Type: 16 tactile membrane keys (labelable, configurable functions) - Navigation: 4-directional keypad + "Enter"/"Escape" keys - Feedback: Audible beeper (3 volume levels) + per-key LED indicators - Key Lifespan: 5,000,000 actuations per key (min.)	Tactile keys reduce input errors; labelable design adapts to application-specific commands (e.g., "Start Batch," "Acknowledge Alarm")

• I/O & Communication Specifications:

  Parameter	Details	Performance Metrics
  Localized I/O	- Digital Inputs: 8 channels (24V DC, optically isolated) - Digital Outputs: 8 channels (24V DC, solid-state MOSFET, 0.5A per channel) - Analog Inputs: 4 channels (4~20mA, 12-bit resolution) - Signal Conditioning: Built-in low-pass filter (1ms~10ms) for analog/digital signals	Localized I/O reduces wiring to central S800 racks; optical isolation eliminates ground loops between field devices
  Communication Interfaces	- Primary: ABB S800 bus backplane (direct integration with S800 controllers) - Secondary: 1× RS-485 port (Modbus RTU, 9.6kbps~115.2kbps) for third-party device connectivity - Service: 1× USB 2.0 port (configuration/backup) - Data Refresh: <200ms (HMI display ↔ S800 controller)	Fast backplane communication ensures real-time data sync; Modbus RTU support enables integration with legacy sensors/actuators

• Mechanical & Environmental Specifications:

  Parameter	Details	Performance Metrics
  Mechanical Design	- Dimensions: 140mm (W) × 180mm (H) × 220mm (D) (panel-mount form factor) - Mounting: Panel mount (cutout: 130×170mm) or 19-inch rack mount (with adapter kit) - Housing Material: Flame-retardant aluminum alloy (UL 94 V0) with EMI shielding - Front Panel Protection: IP65 (dust-tight, water-resistant to splashes) - Weight: Approximately 1.3kg - Status LEDs: 6 LEDs (power, S800 comm, I/O status, alarms, USB, fault)	IP65 front withstands washdowns (e.g., food processing); aluminum housing resists vibration (common in manufacturing)
  Environmental Ratings	- Operating Temperature Range: -25℃~+70℃ (-13℉~158℉) - Storage Temperature Range: -40℃~+85℃ (-40℉~185℉) - Humidity Tolerance: 5%~95% RH (non-condensing, 40℃) - Vibration Resistance: 10~500Hz, 2g acceleration (IEC 60068-2-6) - Shock Resistance: 30g (11ms half-sine, IEC 60068-2-27) - Chemical Resistance: Resistant to oils, mild solvents, and sanitizing agents (per IEC 60068-2-11)	Withstands harsh conditions (e.g., oil refineries, automotive plants) without performance degradation

• Compliance Standards: CE, RoHS, IEC 61131-2, UL 508, CSA C22.2 No.14, EN 61326-3-1 (EMC), ATEX II 3G/3D (hazardous area compatible), IEC 61010-1 (electrical safety) |

2. Core Features

• Integrated HMI + Localized I/O: Combines a 4.3-inch display, 16-key input, and 20 localized I/O channels (8 DI, 8 DO, 4 AI) in one module—eliminates the need for separate HMI and I/O extension units, reducing rack space by 40% and wiring complexity in distributed systems (e.g., process skids).
• Industrial-Grade Durability: IP65 front-panel protection, 5,000,000-actuation keys, and aluminum housing—ensures reliable operation in 24/7, high-wear environments (e.g., chemical plant control rooms) and resists damage from dust, water splashes, or accidental impact.
• Multi-Level Security Controls: 4 user permission levels (Operator, Supervisor, Engineer, Admin) + key lock option—restricts access to critical functions (e.g., process setpoint changes, I/O control) to authorized personnel only, complying with safety standards (e.g., ISO 13849) and preventing costly human error.
• Seamless S800 Integration: Direct communication with S800 controllers via backplane—auto-detects connected devices, loads pre-configured I/O mappings, and syncs HMI data in real time; no custom drivers required, reducing commissioning time by 30%.
• Localized I/O Control: 20 built-in I/O channels for digital/analog signals—enables localized control of small-scale processes (e.g., a single process skid) without routing all signals to a central S800 rack, minimizing wiring costs and signal latency.
• Flexible Mounting Options: Panel-mount or 19-inch rack-mount compatibility—adapts to diverse installation scenarios (e.g., custom control panels for hazardous area skids or standard rack-based control rooms), increasing deployment flexibility.
• EMI Shielding: Aluminum housing with built-in EMI shielding—blocks high-frequency interference from VFDs, motors, or industrial equipment (e.g., automotive assembly lines), ensuring stable HMI display and I/O signal processing.
• Multi-Sensory Feedback: Audible beeper, per-key LEDs, and tactile key feedback—confirms successful input in noisy environments (e.g., manufacturing lines with heavy machinery), reducing operator uncertainty and input errors.

3. Application Fields

• Process Control & Oil & Gas: Localized operator control for skids:
  • Chemical Processing Skids: Enables operators to monitor 4 analog process variables (e.g., temperature, pressure) via the LCD and control 8 digital valves (e.g., dosing valves) via localized outputs—IP65 front withstands chemical splashes, while ATEX compliance supports use in Zone 2 hazardous areas.
  • Oil Well Auxiliaries: Uses 8 digital inputs to monitor pump run status and 4 analog inputs to track wellhead pressure—localized control reduces wiring to central S800 racks, simplifying installation in remote field locations.
• Manufacturing Automation: Operator interaction for production lines:
  • Automotive Assembly Lines: Configured with 16 labelable keys for "Start Conveyor," "Stop Robot," and "Acknowledge Jam"—localized I/O controls small actuators (e.g., grippers) to reduce signal latency, ensuring precise synchronization with robotic arms.
  • Electronics Production: Monitors 4 analog test signals (e.g., PCB voltage) and controls 8 digital tool changers—multi-level security prevents unauthorized tool adjustments, reducing defect rates.
• Food & Pharmaceutical Manufacturing: Hygienic operator interface:
  • Food Packaging Lines: IP65 front panel withstands daily washdowns with sanitizing agents—operators use keys to adjust seal temperatures (via analog outputs) and acknowledge low film stock alarms (via digital inputs), complying with FDA hygiene standards.
  • Pharmaceutical Sterilizers: Displays autoclave temperature/pressure (analog inputs) and controls door interlocks (digital outputs)—user permissions restrict sterilization cycle changes to trained engineers, meeting GMP requirements.
• Utilities & Remote Infrastructure: Field-level oversight:
  • Water Treatment Plants: Localized I/O monitors 8 filter pressure switches (digital inputs) and controls 8 backwash valves (digital outputs)—HMI displays filter status, enabling operators to initiate backwashing without accessing the central control room.
  • Solar Farms: Uses 4 analog inputs to track inverter output and 8 digital outputs to control fan cooling—remote mounting (panel-mount) simplifies installation in outdoor inverter cabinets, while EMI shielding resists interference from solar electronics.

4. Precautions

• System Compatibility (Critical): Use only with ABB S800 controllers (e.g., DSDON001, AC 800M) and DSBB-series backplanes—non-S800 systems require custom communication drivers, which may cause HMI-I/O desync or permission control failures; verify via ABB’s DSIH700 compatibility list.
• Installation & Wiring Safety:
  • Sealing Check: Ensure the front-panel gasket is fully seated during panel mounting—misaligned gaskets compromise IP65 protection, allowing water/dust ingress; torque panel screws to 0.8Nm (per ABB guidelines) for a tight seal.
  • I/O Wiring: For localized I/O channels, use twisted-pair shielded cable (0.5~2.5mm²) and ground the shield at one end—prevents ground loops and EMI interference; avoid routing I/O cables near high-voltage lines (e.g., 480V motor cables).
  • Permission Configuration: Set user permission levels during initial setup (via USB)—restrict "Engineer/Admin" levels to critical personnel only; disable unused key functions to prevent accidental input errors.
