ABB DSHM110 5735095-A Display Unit

1. Key Parameters

• Product Model: DSHM110 5735095-A
• Product Series: ABB S800 I/O Industrial Display Units (Field-Level Operator Interface)
• Core Function: Visualizes real-time S800 I/O data (analog/digital signals, trends); displays and prioritizes alarms; enables operator acknowledgment of alerts; supports permissions-based manual control commands; communicates with S800 controllers via backplane
• Display & User Interface Specifications:

  Parameter	Details	Performance Metrics
  Display Panel	- Type: Color TFT LCD (5.7 inches, 640×480 pixels, 256K colors) - Backlight: LED (dimmable, 100,000-hour lifespan) - Viewing Angle: 170° horizontal / 160° vertical (wide-view for multi-operator access) - Brightness: 350 cd/m² (readable in direct sunlight)	Color display enhances data differentiation (e.g., red for alarms, green for normal); wide viewing angle supports team-based monitoring (e.g., on factory floors)
  User Input	- Interface: 12 tactile membrane buttons (labelable, configurable for navigation/control) + 4 softkeys (contextual to screen) - Feedback: Audible beeper (3 volume levels) + visual LED indicators for button presses - Protection: IP65-rated front panel (dust-tight, water-resistant to splashes)	Intuitive input design enables fast interaction (e.g., alarm acknowledgment in <1 second); IP65 front withstands washdowns (e.g., food/pharmaceutical environments)

• Functional & Communication Specifications:

  Parameter	Details	Performance Metrics
  Data Visualization	- Screen Capacity: Up to 32 configurable screens (gauges, trends, digital grids, mimic diagrams) - Supported Data Types: Digital I/O states, analog values (4~20mA/0~10V), counters, timers, alarm logs - Data Refresh Rate: 200ms~1s (configurable per data point)	Flexible screens adapt to diverse applications (e.g., 8 analog gauges for process pressures, 32 digital indicators for valve status)
  Alarm Management	- Alarm Capacity: 256 alarm slots (priority-based: 4 levels) - Alarm Features: Time stamping, cause/effect tracking, acknowledgment logging, auto-scroll for unacknowledged alerts	Priority-based alarms ensure operators address high-risk issues first (e.g., overpressure = priority 1, low level = priority 4)
  Communication	- Primary: S800 bus backplane (direct communication with S800 controllers/I/O) - Secondary: 1× USB port (for configuration/backup) - Protocol Support: ABB S800 native protocol (for I/O data exchange)	Fast backplane communication ensures real-time data sync; USB port enables offline configuration (no system downtime during setup)

• Mechanical & Environmental Specifications:

  Parameter	Details	Performance Metrics
  Mechanical Design	- Dimensions: 140mm (W) × 180mm (H) × 220mm (D) (panel-mount/rack-mount compatible) - Mounting: 19-inch rack mount (with adapter) or panel mount (cutout: 130×170mm) - Housing Material: Flame-retardant aluminum alloy (UL 94 V0) with EMI shielding - Weight: Approximately 1.2kg - LEDs: 6 status LEDs (power, communication, alarms, backlight, USB, fault)	Rigid aluminum housing resists physical impact; dual mounting options fit 19-inch control racks or machine-mounted panels
  Environmental Ratings	- Operating Temperature Range: -30℃~+70℃ (-22℉~158℉) (extended cold operation) - Storage Temperature Range: -40℃~+85℃ (-40℉~185℉) - Humidity Tolerance: 5%~95% RH (non-condensing, 40℃) - Vibration Resistance: 10~500Hz, 2g acceleration (IEC 60068-2-6) - Shock Resistance: 30g (11ms half-sine, IEC 60068-2-27)	Withstands extreme conditions (e.g., arctic pipelines, desert solar farms) without display degradation

• Compliance Standards: CE, RoHS, IEC 61131-2, UL 508, CSA C22.2 No.14, EN 61326-3-1 (EMC), ATEX II 3G/3D (hazardous area compatible) |

2. Key Features

• High-Performance Color TFT Display: 5.7-inch 640×480 color LCD with 350 cd/m² brightness—ensures clear visibility in direct sunlight (e.g., outdoor pump stations) or dim industrial environments (e.g., chemical plant control rooms); 100,000-hour backlight minimizes maintenance.
• IP65-Rated Front Panel: Dust-tight and water-resistant design—withstands daily washdowns (e.g., food packaging lines using sanitizing agents) or harsh field conditions (e.g., oil rig auxiliary control panels), protecting internal electronics from damage.
• Advanced Alarm Management: 256 priority-based alarms with time stamping and logging—auto-scrolls unacknowledged alerts to prevent missed critical issues (e.g., reactor overpressure); logs all actions for compliance (e.g., FDA 21 CFR Part 11 for pharmaceuticals).
• Permissions-Based Control: Restricts manual commands (e.g., valve activation, pump start) to authorized users via password or button lock—prevents accidental or unauthorized changes to process control, enhancing operational safety.
• Seamless S800 Integration: Communicates directly with S800 controllers and I/O modules via backplane—auto-detects connected data points, eliminating the need for custom gateways; USB configuration enables offline screen design (no system downtime during setup).
• Extended Environmental Range: Operates from -30℃ to +70℃—functions reliably in sub-zero environments (e.g., cold-storage facility compressors) or high-heat areas (e.g., steel mill auxiliary systems) without additional heating/cooling.
• EMI Shielding: Aluminum housing with built-in EMI shielding—blocks high-frequency interference from VFDs, motors, or industrial equipment (e.g., automotive assembly lines), ensuring stable display and button operation.
• Dual Mounting Options: Compatible with 19-inch rack or panel mounting—adapts to diverse installation scenarios (e.g., central control racks or machine-mounted local panels), increasing deployment flexibility.

3. Application Fields

• Process Industry Monitoring: Visualizing critical process data:
  • Chemical Plants: Displays reactor temperature/pressure (analog gauges), valve positions (digital indicators), and safety interlock status—alerts operators to overpressure (priority 1 alarm) and enables acknowledgment via softkeys; ATEX compliance supports Zone 2 hazardous areas.
  • Oil & Gas Auxiliaries: Monitors wellhead chemical injection rates (trends) and pump run status (digital grids)—wide temperature range (-30℃~+70℃) withstands desert or arctic field conditions; IP65 front resists dust and oil splashes.
• Food & Pharmaceutical Manufacturing: Hygienic operator interface:
  • Food Packaging Lines: Shows conveyor speed (analog), seal temperature (trends), and product count (counter)—IP65 front withstands daily washdowns with caustic cleaners; color-coded screens differentiate normal (green) vs. fault (red) states.
  • Biopharmaceutical Fermenters: Displays dissolved oxygen (DO), pH levels (analog), and agitation speed—logs all alarm acknowledgments for FDA compliance; permissions restrict manual pH adjustments to trained personnel.
• Remote Infrastructure & Utilities: Field-level oversight:
  • Water Treatment Plants: Visualizes filter pressure (trends), pump status (digital), and chemical dosing levels (gauges)—alerts operators to filter clogging (priority 2 alarm); wide viewing angle supports team monitoring at remote sites.
  • Solar Farms: Shows inverter output (analog), battery charge level (gauge), and fault status (digital)—bright display ensures visibility in direct sunlight; IP65 front resists dust and rain in outdoor installations.
• Manufacturing & Machine Tools: Local operator control:
  • Automotive Assembly Lines: Displays robotic arm position (digital), weld gun current (analog), and conveyor status—alerts to jammed parts (priority 3 alarm) and enables manual line pause via labeled buttons; EMI shielding resists interference from welding equipment.
  • CNC Machining Centers: Visualizes spindle speed (analog), tool change status (digital), and coolant levels (gauge)—alerts to low coolant (priority 2 alarm) and enables manual coolant pump activation (permissions required); panel-mount design fits machine control panels.

4. Precautions

• System Compatibility (Critical): Use only with ABB S800 controllers (e.g., DSDON001, AC 800M) and DSBB-series backplanes—non-S800 systems require custom communication drivers, which may reduce performance or cause display glitches; verify via ABB’s DSHM110 compatibility list.
• Installation & Wiring Safety:
  • Sealing Check: Ensure the front-panel gasket is properly seated during mounting—misaligned gaskets compromise IP65 protection, allowing water/dust ingress; torque panel screws to 0.8Nm (per ABB guidelines) for a tight seal.
  • Grounding: Connect the unit’s PE terminal to a dedicated control ground (resistance ≤1Ω)—shared grounding with power systems causes EMI interference, leading to display flicker or unresponsive buttons.
  • USB Handling: Disconnect the USB cable after configuration—leaving it connected in industrial environments risks physical damage or moisture ingress; use the USB dust cap (included) when not in use.
  •

The structure and details of the product：

Please make an inquiry for more models
