ABB DSDP 140B counting board

• • • • • • • • • 1. Overview

                  The ABB DSDP140B Counting Board is a specialized module for industrial automation and distributed control systems (DCS). It is designed for high-speed pulse signal acquisition and counting. The module is compatible with ABB control systems and provides precise pulse counting, signal acquisition, and data transmission, widely applied in power, metallurgy, chemical, and automated production line systems.

                  ---

                  2. Key Technical Specifications

                  • Model: DSDP140B

                  • Type: Counting Board

                  • Compatible Systems: ABB Distributed Control Systems (Advant / MOD series)

                  • Input Signal Types: Pulse signals, digital input signals

                  • Maximum Counting Rate: Depends on module version and system bus speed

                  • Output Type: Digital signals or processed counting data

                  • Communication Interface: Module bus or system bus interface

                  • Power Supply: System dependent, typically 24 V DC

                  • Operating Temperature: –25 °C to +60 °C

                  • Storage Temperature: –40 °C to +70 °C

                  • Vibration Resistance: Industrial-grade

                  • Mounting: Cabinet or panel installation

                  • Dimensions & Weight: Approx. 150 × 100 × 30 mm, ~0.5 kg

                  ---

                  3. Features & Advantages

                  • High-speed pulse counting for precise signal acquisition

                  • Modular design for easy system expansion and maintenance

                  • Strong compatibility with ABB DCS systems

                  • Industrial-grade reliability: temperature and vibration resistant

                  • Easy installation and maintenance with quick module replacement

                  • High-precision data processing for real-time control and accurate counting

                  ---

                  4. Typical Applications

                  • Distributed Control Systems (DCS)

                  • Industrial automation and process control

                  • Power systems and energy management

                  • Chemical, petrochemical, and metallurgical industries

                  • Production line pulse counting and automation monitoring

                  • Data acquisition and real-time control integration

                  ---

                  5. Notes & Precautions



                  • Ensure proper grounding before installation

                  • Avoid high humidity, dusty, or corrosive environments

                  • Power off before inserting or removing modules

                  • Regularly check module connections and signal quality

                  • Keep spare modules for rapid replacement

                  • Clean with dry compressed air or lint-free cloth to prevent dust ingress
