ABB DP620 3BHT300016R1 High-Speed ​​Counter

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us..

Product Overview

The ABB DP620 3BHT300016R1 is a high-performance High-Speed Counter Module designed for industrial automation and control systems. It provides precise counting and measurement of high-frequency pulse and encoder signals, enabling accurate speed, position, and process data acquisition. The module is typically used with ABB DCS or PLC systems for motor control, synchronization, and process monitoring applications.

Technical Specifications (Typical)

• Model: DP620

• Order No.: 3BHT300016R1

• Function Type: High-Speed Counter Module

• Counting Channels: 2–4 independent high-speed inputs

• Max Input Frequency: up to 500 kHz

• Input Signal Types: TTL / HTL pulses, A/B encoder signals

• Input Voltage Range: 5–30 V DC

• Isolation: Optical isolation between channels and system bus

• Operating Voltage: 24 V DC (±10%)

• Power Consumption: approx. 6 W

• Response Time: < 1 ms

• Operating Temperature: 0 to +55°C

• Storage Temperature: -25 to +70°C

• Humidity: ≤95%, non-condensing

• Protection Rating: IP20 (for use inside control cabinets)

• Mounting: DIN rail

• Dimensions (L × W × H): 130 × 80 × 40 mm

• Weight: approx. 0.6 kg

Features and Advantages

1. High speed and accuracy — Supports counting rates up to 500 kHz for real-time and precise measurement.

2. Multi-signal compatibility — Accepts a wide range of pulse and encoder signal types.

3. Industrial reliability — Designed with strong EMI immunity and galvanic isolation.

4. Flexible configuration — User-defined counting modes and ranges via system software.

5. Plug-and-play modular design — Simplifies installation and system integration.

6. Self-diagnostic function — Monitors operation status and detects potential faults.

Application Areas

• Motor speed and position detection

• Process synchronization and control

• Encoder signal acquisition in production lines

• High-speed assembly and packaging machinery

• Power generation, metallurgy, chemical, and process automation systems

Precautions

1. Always disconnect system power before installation.

2. Ensure input signal levels comply with the module specifications.

3. Avoid installation in environments with excessive heat, humidity, or electromagnetic interference.

4. Periodically inspect wiring and input connections.

5. Installation and commissioning should be performed by trained professionals.

The structure and details of the product：
