ABB DASD103 Control Module

ABB DASD103 Control Module

Product Overview

The ABB DASD103 is a Control Module used in industrial automation systems for core signal processing and execution of control commands in PLC, DCS, or other control systems. The module can process digital and analog signals at high speed, enabling precise control and real-time monitoring of industrial automation equipment. The DASD103 module is compact, stable, and is a key component in factory automation, energy management, and production line control systems.

Main Technical Specifications

• Model: DASD103

• Product Type: Control Module

• Input Type: Digital input (DC 24V), analog input (0-10 V / 4-20 mA)

• Output Type: Digital output (relay or transistor), analog output (0-10 V / 4-20 mA)

• Channel Count: 8–16 digital I/O channels (configurable)

• Response Time: ≤ 1 ms (digital input)

• Supply Voltage: 24 V DC

• Operating Temperature: 0°C to +55°C

• Storage Temperature: -20°C to +70°C

• Protection Rating: IP20 (for control cabinet installation)

• Mounting: DIN rail

• Status Indicators: LED for power and signal status

• Compatibility: Compatible with ABB PLC, DCS, and industrial automation equipment

Advantages & Key Features

• High-speed signal processing for fast and accurate digital and analog control.

• Multi-functional interfaces support various I/O signal types with strong compatibility.

• Modular design with DIN rail mounting for easy expansion and maintenance.

• Industrial-grade durability resistant to vibration, EMI, and high temperatures.

• Visual status indicators with LEDs for each channel and power for easy diagnostics.

• Easy integration with ABB PLC, DCS, and other automation equipment.

Application Areas

• Core control module in industrial automation systems

• Signal acquisition and control in PLC and DCS systems

• Monitoring and control of automated production line equipment

• Robot and manipulator control systems

• Power, petrochemical, metallurgical, and water treatment automation

• Smart manufacturing and Industrial IoT control systems

Precautions

1. Ensure module supply voltage and I/O signal types match the system before installation.

2. Install the module inside a control cabinet or protective enclosure to avoid moisture, dust, and corrosion.

3. Disconnect power before wiring or maintenance to prevent short circuits or accidental operation.

4. Regularly inspect connections, cables, and LED indicators to ensure normal operation.

5. Avoid prolonged overload operation to extend module lifespan.

6. Keep input and output signals within module specifications to prevent damage.

7. Follow industrial safety standards during commissioning and operation to ensure system stability.
