ABB CTB810 control board

ABB CTB810 Control Board

Overview:

The ABB CTB810 Control Board is a versatile and reliable module designed for industrial automation, process control, and energy management systems. It supports a wide range of digital and analog I/O configurations and is compatible with multiple communication protocols like Modbus and Profibus. The CTB810 ensures high performance, real-time diagnostics, and efficient control of industrial processes.

Specifications:

• Model: CTB810

• Input Voltage: 24V DC (nominal)

• Power Consumption: 10W (max)

• Digital Inputs: 8 (24V DC)

• Digital Outputs: 4 (Relay type)

• Analog Inputs: 2 (0-10V, 4-20mA)

• Analog Outputs: 2 (0-10V, 4-20mA)

• Communication Protocol: Modbus, Profibus, CANopen

• Mounting: DIN rail

• Temperature Range: -20°C to +60°C

• Dimensions: 160mm x 120mm x 90mm

• Weight: 0.75 kg

• Protection: IP20

• Certification: CE, UL, RoHS

Features:

• Versatile I/O Configuration

• Supports Multiple Communication Protocols

• Compact, Robust Design

• Efficient Performance

• Real-Time Diagnostics with LED Indicators

• Wide Temperature Range

• Protection Features (Overload, Short-circuit, Overvoltage)

Applications:

• Industrial Automation

• Process Control

• Energy Management

• Machine Automation

• Building Automation

• Remote Control and Monitoring

Precautions:

• Ensure stable 24V DC power supply.

• Proper grounding to avoid electrical faults.

• Do not overload I/O channels.

• Install in an environment free from excessive dust and moisture.

• Operate within the specified temperature range for optimal performance.
