ABB CSP-VI-D-V4-D-A2

ABB CSP-VI-D-V4-D-A2 Control Module

Overview:

The ABB CSP-VI-D-V4-D-A2 control module offers reliable, flexible, and scalable performance for industrial control applications. With support for multiple communication protocols and a wide range of I/O options, it is designed for use in various automated environments such as machine control, process control, energy management, and building automation.

Specifications:

• Model: CSP-VI-D-V4-D-A2

• Power Supply: 24V DC (nominal)

• Power Consumption: 5W max

• I/O Channels: Configurable I/O

• Digital Inputs: 10-16 (depending on configuration)

• Digital Outputs: 6-8 (depending on configuration)

• Analog Inputs: 4 channels (0-10V, 4-20mA)

• Analog Outputs: 2 channels (0-10V, 4-20mA)

• Communication Protocol: Modbus, Profibus, CANopen

• Mounting: DIN rail

• Temperature Range: -20°C to +70°C

• Dimensions: 160mm x 120mm x 90mm

• Weight: 0.6 kg

• Protection: IP20

• Certification: CE, UL, RoHS

Features:

• Flexible I/O Configuration

• Multiple Communication Protocols

• Compact and Robust Design

• Wide Operating Temperature Range

• Real-Time Diagnostics via LED Indicators

• Energy-Efficient

• Seamless Integration with ABB Systems

Applications:

• Industrial Automation

• Process Control

• Machine Automation

• Energy Management

• Building Automation

• Remote Control and Monitoring

Precautions:

• Ensure stable 24V DC power supply.

• Proper grounding is essential.

• Avoid overloading I/O channels.

• Install in an environment free from excessive dust and moisture.

• Periodic maintenance and monitoring of LED indicators for optimal performance.
