ABB CL-LMR.C18AC2 Logic Relay

1. Key Parameters

• Product Model: CL-LMR.C18AC2
• Order Code Reference: Typically paired with ABB logic relay accessory kits (e.g., 3ABD00041022, including programming cable, terminal blocks, and user manual) for procurement consistency
• Product Series: ABB CL-LMR Series Compact Logic Relays (18-I/O, AC Power)
• Core Function: Executes programmable logic (e.g., ladder diagram, function blocks) for small-scale automation; controls digital/analog I/O devices; monitors equipment status; triggers alarms or protective actions; supports basic data logging
• Electrical & I/O Specifications:

  Parameter	Details	Performance Metrics
  Power Supply	AC 230V ±10% (50Hz/60Hz auto-adaptive); No-load current: ≤50mA; Full-load current: ≤200mA	Power consumption: ≤45VA
  Digital Inputs (DI)	12 channels (24V DC, sinking/sourcing); Input voltage range: 18~30V DC (logic "1"), ≤5V DC (logic "0"); Response time: ≤10ms	All inputs with debounce filtering (5ms fixed); Overvoltage protection: ±35V DC
  Digital Outputs (DO)	6 channels (relay output, DPDT/NO-NC); Rated switching voltage: AC 250V / DC 30V; Rated switching current: 5A (resistive load), 2A (inductive load)	Short-circuit protection: Electronic (auto-recovery); Mechanical life: 10 million operations
  Analog Inputs (AI)	2 channels (configurable: 4~20mA DC / 0~10V DC); Resolution: 12-bit; Accuracy: ±1% of full scale	Input impedance: 250Ω (4~20mA), 100kΩ (0~10V); Filtering: 1st-order low-pass (cutoff 10Hz)
  Communication Interface	1× RS485 port (Modbus RTU protocol); Baud rate: 9600~115200 bps; Parity: None/Even/Odd	For remote monitoring/programming via HMI or PLC

• Mechanical Specifications:
  • Housing Type: Flame-retardant polyamide (UL94 V-0); Panel-mounted (DIN 43880 cutout)
  • Dimensions (W×H×D): 72mm × 110mm × 100mm (compact for panel integration)
  • Mounting: Panel-mounted (cutout size: 68mm × 106mm); Secure with 4 M3 screws (torque: 0.8 N·m)
  • Weight: Approximately 320g
  • User Interface: 4-digit 7-segment LED display (for status/value monitoring); 4 pushbuttons (for local parameter adjustment); LED indicators (power, I/O status, communication)
• Environmental Ratings:
  • Operating Temperature Range: -5℃~+55℃ (23℉~131℉)
  • Storage Temperature Range: -20℃~+70℃ (-4℉~158℉)
  • Humidity Tolerance: ≤90% RH (non-condensing, 40℃; suitable for damp commercial environments)
  • Vibration Resistance: 10~500Hz, 1g acceleration (IEC 60068-2-6; no logic or I/O failure)
  • Shock Resistance: 15g acceleration (11ms duration, IEC 60068-2-27; maintains program and settings)
  • Protection Rating: IP20 (front panel; protects against finger contact and small debris)
• Compliance Standards: IEC 61131-2 (industrial control equipment), EN 61000-6-2 (EMC immunity), UL 508 (industrial safety), CE, RoHS, EN 60947-5-1 (low-voltage switchgear)

2. Key Features

• Simplified Logic Programming: Supports intuitive programming via ABB LogicBuilder software (free download) or local pushbuttons/LED display—compatible with ladder diagram (LD), function block diagram (FBD), and structured text (ST) languages. No advanced PLC programming skills required, reducing deployment time for small automation tasks.
• 18-Point I/O Flexibility: 12 digital inputs + 6 relay outputs (DPDT/NO-NC) + 2 analog inputs cover most small-scale control needs (e.g., monitoring 8 sensors + controlling 4 pumps + measuring 2 pressure signals)—eliminates the need for additional I/O modules.
• Industrial-Grade Reliability: 2kVrms isolation between power supply and I/O circuits; ESD protection (±8kV contact/±15kV air) and surge protection (±2kV signal lines) suppress electrical noise from nearby motors or VFDs—ensures stable operation in electrically noisy environments (e.g., packaging plants).
• Relay Output Durability: 5A resistive/2A inductive switching capacity and 10-million-operation mechanical life for digital outputs—suitable for direct control of small loads (e.g., 24V DC solenoid valves, 230V AC small fans) without external contactors.
• Remote Monitoring & Control: Built-in Modbus RTU (RS485) enables communication with ABB HMIs, AC500 PLCs, or third-party SCADA systems—technicians can remotely adjust parameters (e.g., setpoint values) or monitor I/O status, reducing on-site maintenance.
• Local Operation Convenience: 4-digit LED display shows real-time values (e.g., analog input current, output status); pushbuttons allow quick parameter modification (e.g., alarm thresholds) without connecting a PC—ideal for on-site troubleshooting.
• Cost-Effective Automation: Combines PLC-like logic control with the simplicity of a relay, avoiding the cost of a full-size PLC for small tasks (e.g., single-machine control). Lower power consumption (≤45VA) and minimal maintenance further reduce operational costs.

3. Application Fields

• Small-Scale Industrial Machinery: Primary application—control of standalone equipment:
  • Packaging Machinery: Manages film unwinding, sealing, and cutting sequences for small snack packaging lines; 12 digital inputs monitor photoelectric sensors (part presence) and limit switches (door safety), while 6 relay outputs control motors and heating elements—ensures consistent packaging speed and seal quality.
  • Desktop SMT Equipment: Controls PCB positioning and component placement for small-batch SMT machines; 2 analog inputs track linear actuator position (4~20mA), and digital outputs trigger vacuum pumps (for component pickup)—simplifies control without a full PLC.
• Process Control Auxiliaries: Supports secondary control in larger systems:
  • Water Treatment Pump Stations: Manages 2~4 small booster pumps (230V AC); digital inputs monitor pressure sensors (tank level) and float switches (overflow), while logic functions implement "lead-lag" pump rotation to balance wear—integrates with ABB AC500 PLC via Modbus for centralized monitoring.
  • Food Processing Lines: Controls conveyor speed and ingredient dosing for small bakery mixers; analog inputs measure ingredient flow rate (0~10V), and relay outputs trigger dosing valves—complies with food industry hygiene standards (easy-to-clean panel mounting).
• Commercial & Building Automation: Enables simple HVAC and utility control:
  • Office HVAC Auxiliaries: Manages air handling unit (AHU) dampers and fan coils; digital inputs monitor temperature sensors (room temp) and occupancy switches, while outputs control damper actuators—Modbus communication links to building BMS (Building Management System) for energy optimization.
  • Retail Display Coolers: Controls compressor on/off cycles and defrost heaters for small retail coolers; analog inputs track cooler internal temperature (4~20mA), and logic functions prevent short-cycling (protecting the compressor)—reduces energy waste and maintenance.
• Legacy Equipment Upgrades: Modernizes outdated relay-based control:
  • Old Lathe Machines: Replaces mechanical relays in small manual lathes; adds digital inputs for emergency stop and spindle speed switches, while outputs control spindle motor and coolant pump—improves reliability and adds diagnostic features (e.g., overload alarms).
  • Warehouse Conveyor Sections: Upgrades relay control for short conveyor segments (e.g., package sorting); digital inputs monitor photoeyes (package detection), and outputs control conveyor motors—Modbus integration with warehouse WMS (Warehouse Management System) for traffic control.
