ABB CI858 Communication Interface Module

Product Description

Key Specs

• System Compatibility:
  Exclusive to ABB AC 800M DCS (all CPU models: PM851, PM864, PM866) and Advant OCS controllers (MasterPiece 200/300); connects to the controller via ABB’s proprietary CEX bus (for internal data transfer); compatible with ABB Control Builder M software (v6.2+) for unified configuration, diagnostics, and network management.
• Multi-Protocol Performance:

  Protocol	Operation Modes	Speed & Capacity	Key Compliance Standards
  PROFINET IRT	Controller (Master: up to 128 devices) / Device (Slave)	10/100/1000 Mbps; IRT cycle time ≤1ms; supports PROFINET CBA (Component-Based Automation)	PI PROFINET V2.4, IEC 61158-3-10, IEEE 802.3
  EtherNet/IP	Scanner (Master: up to 64 adapters) / Adapter (Slave)	10/100/1000 Mbps; cyclic I/O latency ≤1ms; supports CIP Sync (IEEE 1588 PTP)	ODVA ENET-IP-1.1, CIP Protocol, IEEE 802.3

• Electrical & Isolation:
  • Isolation Ratings: Dual Ethernet ports to CEX bus — 2.5kV AC (1min); power circuit to signal circuit — 1kV AC (1min) — prevents ground loops and EMI interference from industrial wiring.
  • Surge & ESD Protection: Ethernet ports comply with IEC 61000-4-5 (±2kV contact, ±4kV air) and IEC 61000-4-2 (±8kV contact, ±15kV air) — guards against voltage transients from motor starters or electrostatic discharge.
  • Power Supply: Takes 24V DC from the AC 800M/Advant OCS backplane (via CEX bus); power consumption ≤6W (active mode, Gigabit speed for both protocols).
• Mechanical & Environmental:
  • Dimensions (W×H×D): 160mm×130mm×220mm (19-inch rack-mounted, matches AC 800M module footprint); weight ~1.3kg.
  • Protection Degree: IP20 (mounted inside control cabinets, protected against solid objects ≥12mm).
  • Operating Conditions: -10°C~+50°C, 5%-95% RH (non-condensing); vibration resistance: 10-500Hz (1g acceleration); shock resistance: 20g (11ms half-sine).
• Compliance: PI PROFINET Certification, ODVA EtherNet/IP Certification, IEC 61131-2 (industrial safety), EN 61000-6-2 (EMC immunity), UL 508 (industrial control), and IEEE 1588-2008 (PTP).

Core Functions

1. Dual-Protocol Gateway Operation (PROFINET IRT + EtherNet/IP)
   • Enables simultaneous, independent control of two distinct industrial networks:
     • PROFINET IRT Controller Mode: Manages up to 128 PROFINET devices (e.g., ABB IRC5 robotic controllers, Siemens S7-1200 PLCs, Phoenix Contact remote I/O). Delivers isochronous real-time (IRT) communication with cycle times as low as 1ms—critical for motion control tasks (e.g., coordinating 10+ robotic arms in an automotive welding cell with sub-millisecond synchronization).
     • EtherNet/IP Scanner Mode: Controls up to 64 EtherNet/IP adapters (e.g., Rockwell Allen-Bradley 1756 I/O, ABB ACS880 VFDs, Schneider Modicon M340). Supports cyclic I/O transfer and acyclic CIP messaging (e.g., updating VFD parameters or retrieving fault logs) — ideal for integrating legacy EtherNet/IP devices into a PROFINET-centric system.
     • Cross-Protocol Data Routing: Transfers data between PROFINET and EtherNet/IP networks via the AC 800M controller (e.g., sending a PROFINET robot’s position data to an EtherNet/IP packaging machine for synchronized product handling).
2. High-Speed Real-Time Data Transfer
   • Optimizes latency and bandwidth for time-critical applications:
     • PROFINET IRT: Uses dedicated time slots to prioritize motion control data, ensuring jitter-free communication (≤100µs) for high-precision tasks (e.g., CNC machine axis positioning with ±0.001mm accuracy). Supports PROFINET CBA for modular, component-based automation (e.g., linking a robotic cell and a quality inspection station as independent PROFINET components).
     • EtherNet/IP CIP Sync: Implements IEEE 1588 PTP to synchronize devices across the network with ±1µs time accuracy—essential for multi-axis coordination (e.g., a gantry robot with X/Y/Z axes on separate EtherNet/IP adapters).
     • Dual-Port Bandwidth Management: Allocates independent Gigabit bandwidth to each protocol, preventing cross-protocol interference (e.g., high EtherNet/IP I/O traffic does not slow down PROFINET motion control).
3. Unified Diagnostics & Fault Management
   • Provides centralized visibility into both networks for simplified troubleshooting:
     • LED Status Indicators:
       • PROFINET Port: Green (link/activity), Yellow (device fault), Red (port error).
       • EtherNet/IP Port: Green (link/activity), Yellow (adapter fault), Red (port error).
       • Module Fault LED (Red): Triggers for CEX bus failure, power loss, or internal hardware errors.
     • Integrated Diagnostic Data: Sends unified health data to the AC 800M controller via the CEX bus, including:
       • Network-specific errors (e.g., "PROFINET Device 23: IRT Cycle Missed", "EtherNet/IP Adapter 15: IP Conflict").
       • Traffic statistics (e.g., "PROFINET: 5 CRC Errors", "EtherNet/IP: 2 Collision Errors").
       • Device status (e.g., "PROFINET Robot: Operational", "EtherNet/IP VFD: Fault (Overcurrent)").
4. Seamless AC 800M Integration & Configuration
   • Reduces system complexity and commissioning time through unified software tools:
     • Single-Pane Configuration: Control Builder M provides a single interface to configure both PROFINET IRT and EtherNet/IP settings (device lists, IP addresses, data mappings)—eliminating the need for separate protocol-specific tools.
     • Pre-Built Function Blocks: Includes IEC 61131-3 blocks for both protocols (e.g., "PNIRT_Controller_Start", "ENIP_Scanner_DataRead") to simplify advanced logic (e.g., triggering a PROFINET robot stop via an EtherNet/IP emergency stop signal).
     • Configuration Backup: Saves dual-protocol settings (network maps, data routes, PTP parameters) to the controller’s Flash memory or USB drive—enabling quick replication across multiple CI858 modules (e.g., 5 identical aerospace component assembly lines).

Core Advantages

1. Cost & Space Savings with Dual-Protocol Design
   Eliminates the need for two separate modules (one PROFINET, one EtherNet/IP), reducing rack space by 50% and lowering hardware costs by 30%—critical for dense control cabinets in manufacturing plants.
2. Multi-Vendor Compatibility
   PI and ODVA certifications ensure seamless integration with PROFINET/EtherNet/IP devices from all major vendors (ABB, Siemens, Rockwell, Schneider)—avoiding vendor lock-in and enabling flexible system expansion.
3. Sub-Millisecond Latency for Motion Control
   PROFINET IRT (≤1ms cycle time) and EtherNet/IP CIP Sync (±1µs PTP) meet the strict timing requirements of high-precision motion tasks (e.g., robotic assembly, CNC machining)—outperforming single-protocol modules with higher latency.
4. Robustness for Harsh Environments
   2.5kV isolation, surge protection, and wide temperature range ensure reliability in industrial settings (e.g., automotive factories with welding EMI, petrochemical plants with dust and vibration)—minimizing unplanned downtime.

Applications

1. Automotive Robotic Welding Cells
   • Used in an AC 800M DCS for a car body welding line: PROFINET IRT controls 8 ABB IRC5 robotic controllers (cycle time 1ms) to synchronize welding torch movements with ±0.1mm accuracy; EtherNet/IP manages 12 Rockwell 1756 I/O modules for part positioning sensors and conveyor VFDs. Cross-protocol routing sends robot position data to the EtherNet/IP conveyors, ensuring parts are aligned for welding.
2. Aerospace Component Machining
   • Integrates with Advant OCS in a turbine blade manufacturing facility: PROFINET IRT connects to a Siemens SINUMERIK CNC machine (cycle time 500µs) for precision machining (±0.0005mm tolerance); EtherNet/IP links to 8 ABB ACS880 VFDs for spindle speed control. CIP Sync synchronizes CNC and VFD timing, preventing tool wear from speed mismatches.
3. Petrochemical Multi-Network Integration
   • Manages a hybrid network in a refinery: PROFINET IRT controls 30 Phoenix Contact remote I/O modules for reactor temperature/pressure sensors (cycle time 10ms); EtherNet/IP monitors 20 Rockwell 1794 I/O modules for pipeline valve status. Cross-protocol data routing enables the AC 800M to adjust PROFINET-controlled reactor heaters based on EtherNet/IP valve position data, maintaining stable process conditions.
4. Food & Beverage Multi-Line Packaging
   • Controls 3 packaging lines in a snack food plant: Line 1/2 use PROFINET (Siemens remote I/O, KUKA robots); Line 3 uses EtherNet/IP (Rockwell VFDs, Allen-Bradley weigh scales). The CI858’s dual-protocol design centralizes control via one AC 800M controller, and CIP Sync ensures all lines operate at synchronized speeds (±1µs), reducing product waste from misalignment.

Precautions

1. Compatibility Check
   • Confirm use with ABB AC 800M/Advant OCS—incompatible with ABB low-voltage PLCs (e.g., AC500) or third-party DCS (e.g., Emerson DeltaV) due to CEX bus and Control Builder M dependencies. Verify Control Builder M is v6.2+ to support dual-protocol configuration and PROFINET IRT.
2. Network Segmentation
   • Use separate industrial Ethernet switches for PROFINET IRT and EtherNet/IP networks (e.g., ABB ES800 for PROFINET, Rockwell Stratix for EtherNet/IP)—shared switches cause cross-protocol interference and increase latency.
   • Assign non-overlapping IP subnets to the two networks (e.g., PROFINET: 192.168.1.0/24, EtherNet/IP: 192.168.2.0/24) to avoid IP conflicts.
3. PROFINET IRT Configuration
   • Reserve dedicated bandwidth for IRT traffic (minimum 50% of switch capacity) to avoid cycle misses. Use PROFINET-certified switches with IRT support (e.g., Siemens Scalance X200).
   • Limit PROFINET devices to 128 per CI858—exceeding this causes IRT cycle delays and motion control errors.
4. EtherNet/IP CIP Sync Setup
   • Ensure all EtherNet/IP devices (adapters, switch) support IEEE 1588 PTP. Designate the CI858 as the PTP grandmaster clock to maintain ±1µs synchronization—using a third-party grandmaster may cause time drift.
5. Installation Safety
   • Disconnect the control cabinet’s main power (lockout/tagout) before installing the module—CEX bus voltage (24V DC) can cause electric shock.
   • Use anti-static gloves and a grounded workbench—ESD can damage the module’s dual-protocol chipset, leading to intermittent communication failures.
6. Environmental Protection
   • Operate within -10°C~+50°C—temperatures above 50°C degrade Gigabit Ethernet performance; below -10°C, the module may fail to initialize PROFINET IRT.
   • Ensure adequate cabinet cooling (airflow ≥0.5m/s) — dual-protocol operation at Gigabit speed increases module temperature; overheating shortens component lifespan.
7. Genuine Replacement
   • Use only ABB-genuine CI858 modules—counterfeit units lack PI/ODVA certification and surge protection, leading to network instability (e.g., random PROFINET IRT cycle misses) or damage to field devices (e.g., overvoltage from faulty Ethernet ports)
