• • • ABB CI854BK01 / 3BSE069449R1 Interface Module:

      ---

      1. Introduction

      The ABB CI854BK01 (3BSE069449R1) is a PROFIBUS-DP / DP-V1 communication interface module for the AC 800M controller. It enables high-speed, reliable data exchange between the controller and fieldbus devices such as remote I/O, drives, instrumentation, etc. The module is typically delivered together with a TP854 baseplate for mounting.files.kempstoncontrols.com+2Compact Product Suite hardware selector+2

      It supports both Master and Slave configurations, and offers communication line redundancy and master redundancy features to enhance system resilience.

      ---

      2. Technical Specifications

      • Model / Order No.: CI854BK01 / 3BSE069449R1

      • Communication Protocol: PROFIBUS DP / DP-V1

      • Channels: 2 PROFIBUS ports

      • Transmission Speed: 9.6 kbps to 12,000 kbps

      • Redundancy: Line redundancy, optional master redundancy

      • Hot Swap: Supported

      • Max Units on CEX Bus: 12

      • Connector: DB-9 female

      • Typical Power Consumption: ~ 190 mA at 24 V

      • Dimensions: 59 mm (W) × 185 mm (H) × 127.5 mm (D)

      • Weight: ~0.7 kg including baseplate

      • Operating Temperature: +5 °C to +55 °C

      • Storage Temperature: –40 °C to +70 °C

      • Protection: IP20

      • Pollution Degree: 2

      • Certifications: CE, RoHS, Marine (ABS, BV, DNV-GL, LR)

      ---

      3. Features & Advantages

      • Dual PROFIBUS ports and line redundancy for higher reliability

      • Support for master redundancy (paired modules)

      • Hot-swap capability for maintenance

      • Wide speed range to suit different network loads

      • Direct integration with S800 I/O and other I/O systems

      • Capability to connect PROFIBUS PA devices via linking devices

      • Modular delivery including TP854 baseplate

      ---

      4. Typical Applications

      • Enabling PROFIBUS communication for AC 800M systems

      • Bridging controllers and remote I/O / field devices

      • Use in redundant control systems for high availability

      • Integrating PROFIBUS PA devices into DP networks via linking devices

      ---

      5. Installation & Best Practices

      • Power down before insertion/removal

      • Ensure termination resistors are installed at both ends of the PROFIBUS line

      • Match communication parameters (baud rate, address, etc.) correctly

      • Use shielded twisted-pair cables and proper grounding

      • Maintain ambient conditions within specified ranges

      • In master redundancy setups, ensure proper configuration and synchronization

      • Observe power consumption and check status LEDs

      • Verify firmware/engineering software compatibility with the module

      •
      •
    •
    •
  •
