      • ABB A26-30-01 (1SBL241001R8401) Contactor

        Introduction

        The ABB A26-30-01 belongs to ABB’s A-series contactors and is designed for controlling three-phase AC motors and general-purpose electrical loads. This compact and reliable device is equipped with 3 main poles (NO) and 1 auxiliary contact (NC). The coil voltage is 110–120V AC (60Hz) / 110V (50Hz), making it suitable for a wide range of industrial automation and power control applications.

        ---

        Technical Specifications

        • Model: A26-30-01 (1SBL241001R8401)

        • Main Contacts: 3 NO

        • Auxiliary Contacts: 1 NC

        • Rated Operational Current (AC-3, 400V): 26 A

        • Rated Operational Voltage: 690 V AC

        • Rated Insulation Voltage (Ui): 1000 V

        • Rated Impulse Withstand Voltage (Uimp): 8 kV

        • Thermal Current (Ith): 45 A (at 40 °C, free air)

        • Electrical Durability: approx. 1 million operations (AC-3 duty)

        • Mechanical Durability: approx. 10 million operations

        • Coil Voltage: 110–120V AC (60Hz) / 110V (50Hz)

        • Mounting: DIN rail or screw fixing

        • Operating Time: Closing 8–20 ms, Opening 8–15 ms

        • Ambient Temperature: –25 °C to +55 °C

        • Connection Type: Screw terminals, cable compatible

        ---

        Advantages and Features

        1. High Reliability: Complies with IEC/EN 60947-4-1 standards, suitable for demanding industrial environments.

        2. Modular Design: Compatible with auxiliary contact blocks, mechanical interlocks, and accessories.

        3. Excellent Electrical Performance: 8 kV impulse withstand voltage ensures safety and stability.

        4. Long Service Life: Up to 10 million mechanical and 1 million electrical operations reduce maintenance costs.

        5. Easy Installation: DIN rail or screw mounting for quick and flexible installation.

        6. Wide Applicability: Suitable for motor control, lighting, capacitor switching, and industrial automation.

        ---

        Application Areas

        • Start/stop control of industrial motors (pumps, fans, compressors, conveyors, etc.)

        • Electrical control panels and automation systems

        • Lighting and HVAC systems

        • Capacitor bank switching

        • General power distribution and control systems

        ---

        Precautions

        1. Check Coil Voltage: Ensure it matches the actual control voltage to prevent coil damage.

        2. Proper Selection: Choose correct current rating according to load type (AC-1, AC-3, AC-4).

        3. Installation Environment: Maintain good ventilation and avoid excessive heat or humidity.

        4. Tighten Terminals: Secure wiring connections to prevent overheating from loose contacts.

        5. Avoid Overload: Frequent switching or overload conditions may shorten product lifespan.

        6. Regular Maintenance: Inspect contacts, check coil heating, and ensure safe, reliable operation.

  •
  •
  •
  •
    •
    •
  •
