ABB BGDR-11C (3AXD50000049025) Gate Driver Board

1. Key Parameters

• Product Model: BGDR-11C (Order Code: 3AXD50000049025)
• Product Series: ABB BGDR-Series Industrial Power Device Gate Driver Boards (ACS800 Converter Matching)
• Core Function: IGBT gate signal amplification; electrical isolation; overvoltage/overcurrent protection; compatible with ABB ACS800 converters.

2. Core Features

• Device-Specific Matching: Custom-designed for ABB ACS800 series converters and their IGBT modules, ensuring optimal gate signal timing and amplitude.
• High Isolation: 2.5kVrms isolation between control and power circuits prevents high-voltage interference, protecting low-voltage control components.
• Comprehensive Protection: Integrates IGBT desaturation (short-circuit) and overvoltage detection, triggering shutdown within microseconds to avoid device damage.
• Stable Drive Output: ±15A peak current ensures fast, reliable IGBT switching, reducing switching losses and improving converter efficiency.

3. Application Fields

• Industrial Frequency Converters: Drives IGBT modules in ABB ACS800 converters for motor speed control (e.g., pumps, fans, conveyors).
• Power Conversion Systems: Controls power semiconductors in auxiliary converters for railway, marine, or renewable energy equipment.
• Heavy-Duty Inverters: Supports high-power IGBT switching in industrial inverters for welding machines, extruders, and large-scale machinery.

4. Precautions

• Compatibility: Use exclusively with ABB ACS800 converters and matched IGBT modules; mismatched devices may cause switching failures.
• Installation: Follow ESD protection (anti-static wristband); ensure firm connection to main board and IGBT gate terminals.
• Cooling: Verify heatsink contact during replacement to prevent overheating; clean thermal interface regularly.
• Spare Parts: Use genuine ABB BGDR-11C units—non-genuine boards may have unstable signal output, leading to IGBT damage or converter faults.
