ABB BC6-30-01-01 Compact 3-pole contactor

ABB BC6-30-01-01 Compact 3-Pole Contactor Product Information

Overview:

The ABB BC6-30-01-01 compact 3-pole contactor is a high-performance electrical control device widely used in industrial automation systems, power distribution, and building facility control. Its compact design makes it suitable for controlling motor starters and other loads in space-constrained environments. The contactor is built for long-term reliability, offering excellent durability and resistance to interference, ensuring safe and stable operation of electrical systems.

Detailed Specifications:

• Model: BC6-30-01-01

• Rated Operating Voltage: 400V AC

• Rated Current: 30A

• Contact Configuration: 3 Normally Open (NO) contacts

• Contact Load Capacity: High load capacity, suitable for motor and high-power load control

• Operating Voltage Range: 230V AC to 400V AC

• Mechanical Life: ≥ 1 million operations

• Electrical Life: 100,000 operations

• Maximum Contact Current: 30A

• Protection Class: IP20

• Operating Temperature Range: -25°C to +60°C

• Mounting Type: DIN rail mounting

• Dimensions: 90mm x 80mm x 50mm

• Weight: Approx. 0.5 kg

• Certification Standards: CE, UL certified, compliant with international electrical standards

• Applicable Industries: Industrial automation, power distribution, building facilities, motor control, etc.

Advantages and Features:

1. Compact Design
   The BC6-30-01-01 contactor features a compact design, making it ideal for installation in space-limited electrical control panels while providing efficient control functions.

2. High Load Capacity
   This contactor can handle up to 30A of current load, making it suitable for motor, fan, pump, and other high-power applications.

3. Long Service Life and High Reliability
   The contactor offers over 1 million mechanical operations and 100,000 electrical operations, providing long-term stability and reducing maintenance needs in high-frequency operational environments.

4. Excellent Anti-Interference Performance
   Designed to operate in noisy electrical environments, the BC6-30-01-01 contactor offers strong resistance to electromagnetic interference, ensuring stable performance.

5. Easy Installation and Maintenance
   The contactor supports DIN rail mounting, making installation easy and convenient, while its modular design allows for easy maintenance and replacement, increasing system flexibility.

6. High Safety
   Equipped with short-circuit protection and overload protection, the contactor helps prevent damage to electrical equipment from excessive loads, ensuring the safety and reliability of the system.

Applications:

1. Industrial Automation
   The BC6-30-01-01 contactor is widely used in automated production lines to control motors, conveyors, and other machinery, ensuring efficient and reliable operation.

2. Power Distribution Systems
   This contactor is commonly used in power distribution systems to switch electrical circuits on and off, providing safe power management and load distribution.

3. Motor Control
   The BC6-30-01-01 contactor is ideal for motor control systems, efficiently controlling motor starting, stopping, and reversing to ensure stable operation of motors.

4. HVAC Systems
   In HVAC systems, the BC6-30-01-01 contactor is used to control large motors for air conditioning, ventilation fans, and other equipment, ensuring efficient system operation.

5. Pump and Fan Control
   The contactor is used for controlling pumps and fans, making it suitable for high-power equipment where reliable and stable load switching is essential.

6. Building Automation
   In building automation systems, the BC6-30-01-01 contactor is used to control power, lighting, and HVAC systems, improving energy efficiency and ensuring safety in the building's electrical systems.
