ABB AF190-30-22-13 1SFL487002R1322 magnetic contactor

ABB AF190-30-22-13 1SFL487002R1322 Magnetic Contactor Product Information

Overview:

The ABB AF190-30-22-13 1SFL487002R1322 magnetic contactor is a high-performance electrical control device widely used in power systems, automation equipment, and industrial machinery for switching and protection. The contactor provides stable current switching functions, suitable for various heavy load starting and stopping applications. It has excellent anti-interference capabilities, ensuring the safe operation of electrical systems in complex working environments.

Detailed Specifications:

• Model: AF190-30-22-13 1SFL487002R1322

• Rated Operating Voltage: 230V AC / 400V AC

• Rated Current: 30A

• Coil Voltage: 24V DC / 110V AC / 230V AC

• Contact Configuration: 3 NO (Normally Open) contacts, 1 NC (Normally Closed) contact

• Contact Load Capacity: Supports heavy load currents, suitable for industrial equipment use

• Mechanical Life: Over 1 million operations

• Electrical Life: 100,000 operations

• Maximum Contact Current: 30A

• Protection Class: IP20

• Operating Temperature Range: -25°C to +60°C

• Mounting Type: DIN rail mounting

• Dimensions: 120mm x 100mm x 90mm

• Weight: Approx. 1.2 kg

• Certification Standards: CE, UL certified, compliant with international electrical standards

• Applicable Industries: Industrial automation, machinery, power distribution systems, etc.

Advantages and Features:

1. High Reliability
   The AF190 magnetic contactor is built with high-quality materials and strict manufacturing processes, providing excellent resistance to electrical interference and ensuring reliable operation in noisy electrical environments.

2. Long Service Life
   The contactor is designed for a long mechanical and electrical life. It can perform over 1 million mechanical operations and 100,000 electrical operations, making it ideal for busy industrial environments.

3. High Load Capacity
   The AF190-30-22-13 contactor can handle high current loads, making it suitable for heavy load switching applications in power systems, supporting motor and equipment start/stop operations.

4. Flexible Control Options
   The contactor supports multiple coil voltage options, allowing users to select the appropriate voltage configuration for their specific needs.

5. Compact Design and Easy Installation
   With a compact design, the AF190 contactor is ideal for installation in confined spaces in control panels, and it supports DIN rail mounting for easy integration with other control modules.

6. Excellent Overload Protection
   The contactor provides superior short-circuit and overload protection features, preventing damage to electrical equipment due to excessive load and ensuring system safety.

Applications:

1. Industrial Automation
   The AF190 magnetic contactor is widely used in automated production lines to control heavy-duty motors, pumps, fans, and other equipment, providing reliable overload protection.

2. Power Distribution Systems
   The contactor is commonly used in power distribution systems to safely switch electrical circuits on and off, ensuring secure and efficient power control.

3. Machinery Control
   In machinery, the AF190 magnetic contactor is used to control motor starting and stopping, capable of handling high current loads to ensure reliable operation under heavy-duty conditions.

4. HVAC Systems
   The AF190 contactor is used in HVAC systems to control large motors for air conditioning and ventilation fans, offering stable and efficient control.

5. Pump and Fan Control
   The AF190 magnetic contactor is frequently used for switching pumps, fans, and other high-power equipment, ensuring smooth operation in demanding environments.

6. Building Automation
   The contactor is applied in building automation systems for controlling power, HVAC, and lighting systems, ensuring efficient operation across the building’s electrical systems.

Precautions:

1. Correct Coil Voltage Selection
   Ensure the correct coil voltage is selected based on the actual application environment to ensure reliable operation of the contactor.

2. Avoid Overload Operation
   While the AF190 contactor can handle high loads, it should not be operated beyond its rated capacity to prevent damage or reduced lifespan.

3. Environmental Compatibility
   Ensure the contactor operates within the specified temperature and humidity ranges. Avoid using it in extreme temperatures or high-humidity environments.

4. Regular Inspection and Maintenance
   Regularly inspect the contactor's contacts and coil to ensure they are not worn or damaged, which could impact the normal operation of the equipment.

5. Electromagnetic Interference Protection
   In environments with high electromagnetic interference, implement proper shielding measures to ensure the contactor operates reliably.
