ABB AX410/5200C Single-Input and Dual-Input Analyzers

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

1. Product Overview

The ABB AX410/5200C analyzers are high-precision single-input (AX410) and dual-input (AX5200C) power analyzers designed for industrial and commercial power systems. They provide real-time monitoring of voltage, current, active power, reactive power, power factor, energy, and power quality parameters. With multiple communication protocols, they can be easily integrated into energy management systems or PLCs for energy optimization and intelligent monitoring.

2. Technical Specifications

Electrical Specifications

• Model: AX410 (Single Input) / AX5200C (Dual Input)

• Rated Voltage: 57.7 … 690 V AC (line voltage)

• Rated Current: 1 A or 5 A (expandable via CTs)

• Frequency Range: 50 / 60 Hz

• Power Measurement: Active, reactive, apparent power

• Power Factor Range: -1 … +1

• Energy Accuracy: ±0.2% typical

• Energy Accumulation: Forward, reverse, total energy

• Power Quality Analysis: Voltage/current harmonics, flicker, 3-phase unbalance

• Input Type: Single or dual input (phase/line current)

• Sampling Rate: High-speed for transient capture

Communication & Interfaces

• Communication Protocols: Modbus RTU, Modbus TCP/IP, Profibus, Ethernet

• Relay Outputs: Optional for alarms or event triggers

• Analog Outputs: Optional 0–20 mA / 4–20 mA

• Display: LCD or graphical interface for real-time parameters

Environmental & Installation

• Operating Temperature: –20°C … +60°C

• Storage Temperature: –40°C … +85°C

• Protection Degree: IP20 (panel or cabinet mount)

• Mounting: Panel mount or DIN rail

• Dimensions: Approx. 96×96 mm (panel type) or 144×144 mm (advanced type)

3. Advantages & Key Features

1. High-precision measurement of active, reactive, apparent power, and power quality.

2. Flexible input options for single or dual input applications.

3. Multiple communication protocols enable seamless system integration.

4. Relay and analog outputs for alarms and control triggering.

5. High-speed sampling and event logging for energy management and power quality analysis.

6. Compact design for panel or DIN rail installation, easy maintenance.

4. Application Areas

• Industrial plants and production line power monitoring

• Commercial building energy monitoring and management

• Substation and distribution system energy analysis

• Power quality monitoring and harmonic analysis

• Data center and telecom power monitoring

• Renewable energy generation monitoring (wind, solar)

5. Precautions

1. Verify voltage and current ratings before installation.

2. Avoid high temperature, high humidity, and strong vibration environments.

3. Follow wiring diagrams strictly to ensure measurement accuracy and safety.

4. Perform periodic calibration and inspection to maintain long-term accuracy.

5. Ensure communication cables are properly shielded and grounded to avoid interference.
