ABB AFPS-01C fan power board

ABB AFPS-01C Fan Power Board Product Information

Overview:

The ABB AFPS-01C fan power board is a key component designed by ABB for its fan control systems. It ensures efficient power transfer and stable control functions, widely used in fan-driven systems to ensure the safety, reliability, and efficient operation of equipment. With advanced electronics and a modular design, the AFPS-01C can handle high current loads and provide fast response times. Its superior performance makes it suitable for long-term stable operation in complex industrial environments, particularly in fan systems, HVAC, air conditioning, and industrial equipment.

Detailed Specifications:

• Model: AFPS-01C

• Input Voltage Range: 380V - 480V AC

• Rated Power: 0.75 kW - 45 kW (depending on system power requirements)

• Input Frequency: 50/60 Hz

• Rated Current: Up to 100A (depending on the power board model)

• Output Voltage: Same as input voltage

• Control Method: Vector Control / V/F Control

• Cooling Method: Forced ventilation

• Dimensions: 200mm x 150mm x 120mm (depending on model)

• Protection Class: IP20 (optional IP21)

• Communication Interface: Modbus RTU, Profibus DP (optional)

• Ambient Temperature Range: -10°C to +50°C

• Overload Capacity: 150% rated current, 1 minute

• Display Type: LED indicators for status

• Safety Features: Overload protection, over-temperature protection, short circuit protection, undervoltage protection, overvoltage protection

• Certifications: IEC 61800-5-1, UL, CE

Advantages and Features:

1. High Efficiency and Stability
   The AFPS-01C fan power board is designed for high efficiency, optimizing power transmission in fan control systems, reducing energy waste, and ensuring long-term stable operation.

2. Modular Design
   Its modular design simplifies maintenance and replacement, reducing system downtime and improving reliability and service efficiency.

3. High Power Handling Capability
   The fan power board can handle large power loads, supporting a wide power range from 0.75kW to 45kW, making it suitable for various fan systems and especially for industrial equipment requiring high power transfer.

4. Flexible Communication Options
   With communication interfaces such as Modbus RTU and Profibus DP, it can integrate with upper-level systems such as PLCs and DCS, enabling remote monitoring and control for optimized system performance.

5. Reliable Protection Features
   Built-in protection mechanisms prevent damage from voltage fluctuations, overloads, and other issues, ensuring system safety and stability.

6. Compact and Easy to Install
   The power board is compact and adaptable to various installation environments, with LED status indicators to provide real-time monitoring for user convenience.

7. High Adaptability
   The AFPS-01C fan power board operates reliably across a wide temperature range, making it suitable for industrial, commercial, and HVAC applications in challenging environments.

Applications:

1. HVAC Systems
   In HVAC systems, the AFPS-01C fan power board is widely used for powering and controlling fan systems, helping save energy and improve system performance.

2. Industrial Fan Control
   Applied in various industrial fan systems, such as cooling fans, ventilation systems, and exhaust systems, the AFPS-01C provides stable and reliable power transmission for efficient operation.

3. Water Treatment and Environmental Control
   Used in sewage treatment and environmental air control, the AFPS-01C ensures precise power output for stable airflow and reliable operation.

4. Building Electrical Systems
   In commercial and industrial buildings, the AFPS-01C powers ventilation and air circulation systems, ensuring stable operation of building environmental control systems.

5. Refrigeration and Cold Chain Management
   In refrigeration systems and cold chain management, the AFPS-01C precisely controls fan power output, helping maintain constant temperatures and meet environmental requirements.

Precautions:

1. Power Supply Matching
   Ensure the input voltage of the fan power board matches the power supply voltage to avoid equipment failure or improper operation.

2. Environmental Temperature
   The operating temperature range for the AFPS-01C fan power board is -10°C to +50°C. Ensure the device is installed in an environment with suitable temperature and good ventilation.

3. Electromagnetic Interference
   When used in environments with high electromagnetic interference, shielding may be necessary to ensure proper operation and prevent system failures.

4. Regular Maintenance and Inspection
   Regularly check the connections, current protection, and LED indicators, and clean the fans and heat sinks to ensure proper cooling and avoid overheating.

5. Safety Operation
   Always follow safety procedures during installation and commissioning, ensuring power is disconnected and necessary protective measures are in place to avoid electrical shock or other hazards.
