ABB AFIN-01C fan inverter

ABB AFIN-01C Fan Inverter Product Information

Overview:

The ABB AFIN-01C fan inverter is a high-performance drive designed for fan applications, utilizing advanced frequency control technology to provide precise fan speed control and energy optimization. It is widely used in various fan systems and is especially suitable for HVAC, ventilation, and air conditioning applications. The AFIN-01C inverter helps to enhance system efficiency, reduce energy consumption, and ensure smooth and reliable system operation. The AFIN series inverters are highly adaptable and stable, making them ideal for demanding industrial environments.

Detailed Specifications:

• Model: AFIN-01C

• Input Voltage Range: 380V - 480V AC

• Rated Power: 0.75 kW - 45 kW (depending on the model)

• Control Method: Vector Control / V/F Control

• Output Frequency Range: 0 - 400 Hz

• Input Frequency: 50/60 Hz

• Output Voltage Range: Same as input voltage

• Ambient Temperature Range: -10°C to +50°C

• Overload Capacity: 150% rated current, 1 minute

• Dimensions: From 200mm x 150mm x 120mm to 400mm x 300mm x 220mm depending on the model

• Protection Class: IP20 (Optional IP21 for different environments)

• Communication Interface: Modbus RTU, Profibus DP (optional)

• Startup Type: Auto-start, external start

• Cooling Method: Forced ventilation

• Display Type: LED digital display with status indicators

• Safety Features: Short circuit protection, overload protection, over-temperature protection, anti-interference

• Certifications: IEC 61800-5-1, UL, CE

Advantages and Features:

1. Energy Efficiency
   The AFIN-01C fan inverter optimizes fan speed control to significantly reduce energy consumption. It adjusts the fan speed based on actual load, ensuring required airflow while minimizing energy use.

2. High Performance Control Technology
   Using vector control or V/F control technology, the inverter provides precise speed control to adapt to load variations, ensuring high system efficiency and stability, particularly in applications requiring smooth airflow regulation.

3. Reliable Protection Features
   The inverter is equipped with multiple protection features including overload, over-temperature, and short circuit protection, enabling reliable long-term operation in harsh environments.

4. Flexible Communication Interfaces
   The AFIN-01C offers communication options such as Modbus RTU and Profibus DP, facilitating integration with higher-level automation systems for remote monitoring and data exchange.

5. High Adaptability
   Designed to perform well in a variety of industrial environments, the AFIN-01C inverter operates reliably even in temperature-varying areas, providing stability in different fan control systems.

6. Ease of Installation and Operation
   Featuring an intuitive LED display and user-friendly interface, the inverter allows for easy setup, adjustments, and monitoring, making it convenient for users.

7. Low Noise Operation
   The inverter provides stable frequency adjustment, reducing vibration and noise in the fan system, making it ideal for noise-sensitive environments.

Applications:

1. HVAC Systems
   Widely used in HVAC systems for controlling fan and air conditioning systems, optimizing energy savings, and ensuring smooth system operation.

2. Industrial Fan Systems
   Applied in industrial production lines for cooling fans, exhaust systems, and air handling units, adjusting fan speeds based on demand to improve operational efficiency.

3. Water Treatment and Environmental Control
   Used in sewage treatment, environmental control, and exhaust systems, the AFIN-01C inverter offers precise airflow regulation for energy-efficient and stable operations.

4. Building Electrical Systems
   Controls air circulation and ventilation in commercial and industrial buildings, ensuring air quality and energy efficiency.

5. Refrigeration and Cold Chain Management
   Optimizes fan operation in refrigeration systems and cold chain management, maintaining constant temperatures and adapting to environmental conditions.

Precautions:

1. Power Supply Matching
   Ensure the power supply voltage matches the inverter requirements to avoid equipment failure.

2. Environmental Temperature Control
   Install the inverter in a dry, well-ventilated environment to prevent damage from prolonged exposure to high temperatures or humidity.

3. Electromagnetic Interference
   In high-electromagnetic-interference environments, add shielding measures to ensure the inverter operates normally and safely.

4. Regular Maintenance and Inspection
   Regularly check the inverter’s operating condition, clean the heat sinks and fans to maintain proper cooling and prevent overheating.

5. Safety Operation
   Always disconnect the power and follow safety measures during installation and commissioning to prevent electrical shock or other accidents.
