ABB AF16-30-10-13 1SBL177001R1310 3-Pole Contactor

Introduction

The ABB AF16-30-10-13 is a 3-pole contactor from the ABB AF series, rated at 16 A with one normally open (NO) auxiliary contact. Designed in compliance with IEC/EN 60947-4-1, it is widely used in motor control, power switching, and industrial automation applications.

With AF technology (electronically controlled coil), it ensures reliable performance across a wide control voltage range while reducing energy consumption and enhancing system compatibility.

Technical Specifications

• Model: AF16-30-10-13

• Order Code: 1SBL177001R1310

• Series: AF series

• Poles: 3 (3-pole)

• Auxiliary Contacts: 1 NO

• Rated Current (AC-3, 400V): 16 A

• Motor Rating (AC-3, 400V): 7.5 kW

• Coil Voltage: 100 … 250 V AC/DC (wide range coil)

• Control Circuit: Electronic coil, supports AC/DC inputs

• Mechanical Life: ~10 million operations

• Electrical Life: ~1.5 million operations (AC-3)

• Mounting: DIN rail / screw mounting

• Operating Temperature: -40℃ to +70℃

• Protection Class: IP20 (with terminal cover)

• Certifications: CE, UL, CSA, CCC, RoHS

Features & Benefits

1. AF Electronic Coil – Wide voltage range (100–250 V AC/DC), reducing inventory.

2. High Reliability – Built-in surge suppression for superior EMC performance.

3. Energy Efficient – Low coil power consumption reduces energy loss and heat.

4. Long Service Life – High mechanical and electrical endurance.

5. Flexible Installation – Suitable for DIN rail or screw mounting.

6. Expandable – Auxiliary contact blocks can be added as needed.

7. Global Standards – Fully certified for worldwide use.

Applications

• Motor Control – Start/stop control, reversing applications

• Industrial Automation – Machinery, production line equipment

• Power Systems – Distribution boards, switchgear

• Building Services – HVAC, pumps, fans

• Energy & Infrastructure – Wind, solar, and transport systems

Installation & Maintenance Notes

1. Voltage Selection – Ensure the coil voltage matches the application.

2. Wiring – Use proper conductor sizes and terminals for secure connections.

3. Environmental Conditions – Avoid corrosive gases and high humidity.

4. Overload Protection – Always pair with overload relays for motor protection.

5. Periodic Inspection – Monitor contact wear and coil condition.

6. Mounting Orientation – Can be mounted vertically or horizontally with proper ventilation.

The structure and details of the product：
