ABB ACS550-01-045A-4 AC Drive

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

1. Product Overview

The ABB ACS550-01-045A-4 AC Drive is a general-purpose variable frequency drive (VFD) designed for industrial AC motor speed control and energy management. It provides 45 kW output power, supports three-phase AC motors, features high-performance control, built-in protections, and energy-saving functions, suitable for various industrial automation and machinery applications.

2. Technical Specifications

• Model: ACS550-01-045A-4

• Brand: ABB

• Type: AC Drive / Variable Frequency Drive

• Rated Power: 45 kW

• Input Voltage: 380–480 V AC, three-phase, 50/60 Hz

• Output Voltage: 0–480 V AC, adjustable

• Rated Output Current: 89 A

• Control Methods: V/f control, Sensorless Vector Control

• Frequency Range: 0–500 Hz

• Overload Capacity: 150% rated current for 1 minute

• Efficiency: > 98%

• Operating Temperature: ‑10 °C to +50 °C

• Protection Rating: IP21 (standard indoor), optional IP55

• Interface: Built-in keypad/display, remote control supported

• Communication: Modbus RTU, optional Profibus DP, DeviceNet

• Mounting: Panel or wall-mounted

• Protection Functions: Overcurrent, overvoltage, undervoltage, overheat, phase loss, short-circuit

3. Key Advantages & Features

1. High-Performance Motor Control – V/f and sensorless vector control for smooth start-up and precise speed control.

2. Energy Savings – Optimizes motor speed and load to reduce energy consumption.

3. Intelligent Protection – Built-in motor and drive protections enhance reliability.

4. Easy Installation & Operation – Compact design, intuitive keypad, and multiple communication interfaces.

5. Industrial-Grade Robustness – Reliable operation in harsh industrial environments.

6. Expandable Functionality – Supports I/O and communication expansion modules, PLC integration.

4. Typical Applications

• Industrial machinery: conveyors, cranes, fans, pumps, compressors

• Automation: packaging, printing, textile, and food processing equipment

• HVAC systems and energy management

• Automated production lines and machine tools

• Motor speed and torque control applications

5. Installation & Usage Notes

1. Power Supply – Ensure stable supply voltage matching the drive’s rated input.

2. Grounding & Safety – Properly ground the drive and avoid contact with live parts.

3. Environmental Conditions – Avoid high humidity, dust, or corrosive gases; provide ventilation.

4. Cooling & Heat Management – Maintain sufficient airflow to prevent overheating.

5. Parameter Setting & Commissioning – Configure according to motor specifications and load conditions.

6. Regular Maintenance – Inspect wiring, fans, and operational status to ensure reliable long-term operation.
