ABB 48980001AP DC/DC Converter

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

1. Product Overview

The ABB 48980001AP DC/DC Converter is a high-performance DC/DC voltage converter designed for industrial automation, control systems, and power distribution applications. It converts DC input voltage to a stable, regulated DC output, ensuring reliable power supply for PLCs, DCS, sensors, and control modules. Compact and efficient, it is suitable for panel or cabinet installation.

2. Technical Specifications

• Model: 48980001AP

• Brand: ABB

• Type: DC/DC Converter

• Input Voltage Range: 24–250 V AC/DC

• Output Voltage: 24 V DC

• Maximum Output Current: ~3 A

• Efficiency: High efficiency, low power loss

• Operating Temperature: ‑20 °C to +70 °C

• Storage Temperature: ‑40 °C to +85 °C

• Mounting: DIN rail or panel installation

• Dimensions (approx.): 211.5 mm × 58.5 mm × 121.5 mm

• Weight (approx.): 0.5–0.6 kg

• Protection: Overload and overvoltage protection

• Applications: Industrial automation cabinets, distributed control systems (DCS), PLC power modules

3. Key Advantages & Features

1. Stable and Reliable Power Conversion – Provides consistent DC voltage output for control modules.

2. Wide Input Voltage Range – Supports 24–250 V AC/DC inputs for versatile field conditions.

3. Compact and Space-Saving – Modular design allows flexible installation.

4. High Efficiency and Low Heat Generation – Energy-efficient with low thermal rise.

5. Industrial-Grade Reliability – Operates reliably across a wide temperature range.

6. Enhanced System Safety – Built-in overload and overvoltage protection reduces equipment risk.

4. Typical Applications

• Power supply management for industrial automation systems

• DC supply for PLC and DCS modules

• Stable power for sensors, relays, and control units

• Power isolation and regulation for instrumentation and smart devices

• Control cabinets and field control stations

• Any low-voltage system requiring regulated DC output

5. Installation & Usage Notes

1. Match Input Power – Ensure input voltage is within specified range.

2. Proper Installation – Mount in a ventilated cabinet for heat dissipation and safety.

3. Correct Wiring – Observe polarity and torque for all terminals.

4. Environmental Conditions – Avoid high humidity, dust, or corrosive environments.

5. Regular Maintenance – Periodically check output voltage and temperature for reliability.
