ABB 800PEC 3BHE020455R0003 Control Module

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

• •

  • 1. Product Overview

    The ABB 800PEC 3BHE020455R0003 is a high-performance industrial control module designed for ABB 800xA Distributed Control Systems (DCS) or ABB PLC systems. It features an embedded high-speed processor, digital and analog interfaces, supporting real-time data acquisition, control logic execution, and fault diagnostics, providing reliable control and monitoring for complex industrial processes.

    ---

    2. Technical Specifications

    • Model: 800PEC 3BHE020455R0003

    • Type: Control Module

    • Processor Type: High-speed embedded CPU

    • Input/Output Interfaces: Digital I/O (DI/DO), Analog I/O (AI/AO)

    • Communication Interfaces: PROFIBUS, Modbus, Ethernet, and other industrial buses

    • Supply Voltage: 24 V DC

    • Power Consumption: ~15 W

    • Operating Temperature: 0°C ~ +60°C

    • Storage Temperature: -40°C ~ +85°C

    • Protection Class: IP20

    • Mounting: DIN rail or control panel

    • Dimensions (H×W×D): ~160 × 100 × 50 mm

    • Status Indicators: LED for power, communication, and module status

    ---

    3. Features & Advantages

    1. High-performance control — Embedded high-speed processor supports complex logic and real-time control.

    2. Multi-interface compatibility — Provides digital/analog I/O and multiple industrial communication interfaces for easy integration.

    3. High reliability — Industrial-grade design with strong interference immunity for harsh environments.

    4. Easy installation and maintenance — Standard DIN rail or panel mounting, with LED status indicators for debugging and fault diagnosis.

    5. Strong scalability — Seamlessly integrates with ABB 800xA DCS or other control systems for centralized monitoring and automation.

    6. Fault diagnostic capability — Supports self-test and fault reporting to enhance system reliability.

    ---

    4. Typical Applications

    • Industrial automation control systems

    • Process control in power, petrochemical, and metallurgical industries

    • Core control in Distributed Control Systems (DCS)

    • PLC system expansion modules

    • Factory production line automation monitoring and management

    ---

    5. Precautions

    • Installation and wiring must be performed by qualified personnel, ensuring compliance with power supply and interface specifications.

    • Avoid high humidity, high temperature, and corrosive environments; use protective covers if necessary.

    • Ensure all interfaces are correctly connected before powering on the module to prevent damage.

    • Regularly inspect terminal connections and module status to ensure long-term reliable operation.

    • Perform commissioning and parameter setting according to system manuals to avoid misoperation.

    • Disconnect power before disassembling or servicing the module for safety.

  •
  •
