ABB 70AA02a-E Analog Output Module

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

Module Description / Function

The ABB 70AA02a-E module is an analog output unit designed to convert control system (PLC / DCS) digital/internal signals into standard analog outputs. These outputs drive field devices such as actuators, valves, transmitters, instruments and other analog-input equipment. This module suits applications requiring accurate and stable analog control signals in industrial automation and process control systems.

Key Technical Specifications (typical / publicly indicated — verify against actual module datasheet)

• Output signal type: Analog output (current or possibly voltage, depending on variant)

• Output range: Commonly 0–20 mA (current output) — may also support voltage output depending on configuration / system variant

• Power supply: 24 V DC (standard for module operation)

• Channel configuration: Typically a small number of output channels (e.g. 2 channels, depending on version)

• Output precision / resolution: High precision — output accuracy around ±0.1% full-scale (F.S.)

• Mounting / Installation: Modular slot / rack-based installation, suitable for integration into ABB control cabinets / DCS racks

• Environmental / Reliability: Designed for industrial environments; stable, robust design for continuous operation

• Load driving capability: Able to drive standard analog loads — instruments, valves, transmitters, control devices compatible with standard analog signals

Advantages & Features

• Accurate and stable analog output — suitable for precise control of process variables, e.g. flow, pressure, temperature, level, etc.

• Modular and rack-mountable design — easy integration, replacement, and maintenance in control cabinets / DCS racks

• Good compatibility and versatility — supports standard analog signal output (e.g. 4–20 mA), works with a wide range of field devices and instrumentation

• Industrial-grade robustness / reliability — suitable for continuous operation in harsh industrial environments

• Broad applicability — usable for simple instrumentation output to complex process control in DCS / PLC systems

Typical Application Fields

• Chemical / petrochemical / refinery plants — analog control or monitoring of flow, pressure, temperature, level, concentration processes

• Water treatment and wastewater treatment plants — driving control valves, flow/pump control, monitoring instrumentation, process automation

• Power / energy systems — controlling steam, flow, pressure, temperature, valve actuators, instrumentation outputs

• Industrial manufacturing / process industry — driving actuators, control valves, instruments in production lines and process control systems

• Automation / DCS / PLC control systems for large-scale process control — upgrading or customizing output points, integrating field devices, valves, actuators, etc.

Precautions & Recommendations

• Confirm module variant and output type before installation — ensure compatibility with the downstream analog load (current or voltage)

• Check output channel count vs system requirements — choose module version that matches number of analog outputs needed

• Ensure proper load matching and wiring practice — verify load impedance, use proper shielding or grounding where required, avoid excessive loads

• Install module properly in designated rack / slot to ensure mechanical and electrical compatibility within the control system

• Consider environmental conditions — ensure module suitable for temperature, humidity, noise, and interference present in the industrial environment

• Perform calibration and verification during commissioning — verify output signals match expected values, ensure long-term stability and accuracy

• Maintain documentation / datasheet — keep original datasheet or manufacturer documentation for reference during maintenance, troubleshooting, or future expansion

.
