ABB 5SHY3545L0009 High Voltage Converter Board

• 1. Overview

  The ABB 5SHY3545L0009 High Voltage Converter Board is a core module for high-power industrial drives and power electronic systems.
  It integrates high-voltage semiconductor devices (Thyristor/IGBT) and protective control circuitry to provide efficient energy conversion, rectification, and inversion.
  Widely used in high-power converters, DC traction systems, rectifiers, and HV power transmission, this module ensures stable operation under high voltage and high current conditions.

  ---

  2. Key Technical Specifications (Typical)

  Electrical

  • Model: 5SHY3545L0009

  • Type: High Voltage Converter Board

  • Operating Voltage: High-voltage range (typical 3–5 kV)

  • Rated Current: 2500–3500 A

  • Surge Current (IFSM): > 40 kA (10 ms half-sine)

  • Integrated Devices: Thyristor/IGBT

  • Gate Trigger Current (IGT): 100–200 mA

  • On-State Voltage (VT): 1.2–1.5 V

  • dv/dt & di/dt Capability: Industrial-grade robustness

  Thermal

  • Max Junction Temperature: +125 °C

  • Thermal Resistance: Optimized low RthJC

  • Cooling: Heatsink with air or water cooling

  Mechanical

  • Mounting: Bolt-on installation

  • Material: High-strength industrial insulation

  • Dimensions: Approx. 200 × 150 × 50 mm

  • Weight: 2–3 kg

  Environmental

  • Operating Temperature: –10 °C to +55 °C

  • Storage Temperature: –40 °C to +70 °C

  • Humidity: 5%–95%, non-condensing

  • Vibration Resistance: Industrial-grade

  • EMC: Meets industrial standards

  ---

  3. Features & Advantages

  • High voltage and high current capability

  • Excellent thermal management for stable long-term operation

  • High surge withstand capability

  • Modular design for easy installation and maintenance

  • ABB quality assurance for reliability and long life

  • Integrated protection circuits for overvoltage, overcurrent, and thermal safety

  ---

  4. Typical Applications

  • Medium/High-voltage drives (MV/HV Drives)

  • Grid converters and DC traction systems

  • Industrial rectifiers and inverters

  • Motor soft starters and power transmission devices

  • High-power furnaces and electrolysis equipment

  • Renewable energy power conversion (wind, solar PV)

  • Large UPS power systems

  ---

  5. Notes & Precautions



  • Ensure heatsink flatness and apply thermal compound before installation.

  • Follow recommended bolt torque specifications.

  • Use with compatible gate drive and protection circuits.

  • Ensure cooling system (air/water) is operational during operation.

  • Avoid exposure to high humidity or corrosive environments.

  • Perform all wiring when power is off.

  • Protect the module from frequent high-amplitude surges to ensure long life.
