1. Overview

The ABB 3BHB013085R0001 is a high-performance thyristor module designed for medium- and high-power industrial drive systems, rectifiers, motor control units, converters, and power electronics applications.
It offers excellent surge current capability, high voltage endurance, and superior thermal performance, ensuring long-term stability even in demanding industrial environments.

2. Key Technical Specifications (Typical)

Electrical

• Model: 3BHB013085R0001

• Device Type: High-power Thyristor Module

• Repetitive Peak Reverse Voltage (VRRM): 3800–5000 V

• Average Forward Current (IT(AV)): 2000–3000 A

• Surge Current (IFSM): > 30–40 kA (10 ms half-sine)

• On-State Voltage (VT): 1.2–1.6 V

• Gate Trigger Current (IGT): 80–200 mA

• dv/dt Capability: High industrial immunity

• di/dt Capability: Fast turn-on performance

Thermal

• Maximum Junction Temperature: +125 °C

• Cooling Method: Air or water-cooled heatsink

• Thermal Resistance: Low RthJC for efficient heat dissipation

Mechanical

• Package: Industrial high-power module

• Mounting: Bolt-on

• Insulation: High dielectric strength

• Weight: Approx. 1–2 kg

3. Features & Advantages

• High current and high voltage endurance

• Excellent thermal stability

• Strong surge current capability

• Low on-state voltage for improved efficiency

• Long service life with high industrial reliability

• ABB quality and safety assurance

4. Applications

• Medium- and high-voltage drives

• High-power rectifier and inverter systems

• DC motor control

• Soft starters

• Grid converters and power transmission systems

• Metallurgical furnaces and electrolysis systems

• Railway traction converters

• High-capacity UPS systems

• Renewable energy converters

5. Precautions

• Apply thermal compound evenly before mounting.

• Follow torque specifications for bolts.

• Ensure proper gate drive and protective circuits.

• Maintain effective cooling during operation.

• Avoid corrosive or high-humidity environments.

• Perform wiring only when completely powered off.

• Protect module from excessive surge currents.
