ABB 5SDF0860H0003 diode module

Product Overview:

The ABB 5SDF0860H0003 Diode Module is a key power semiconductor component in ABB industrial power electronics and medium-voltage drive systems. It features a Press-Pack design, providing high reliability and efficient current rectification and power conversion. The module is widely used in ABB medium-voltage drives, power converters, rectifier systems, and industrial automation equipment, serving as a critical component for efficient power control and system protection.

Technical Specifications:

• Model: 5SDF0860H0003

• Brand: ABB

• Type: Diode Module

• Rated Voltage: 6 kV (maximum repetitive peak reverse voltage)

• Rated Current: 860 A (maximum RMS forward current)

• Peak Reverse Voltage: 3,000 V DC

• Reverse Recovery Time: 100 ns

• Operating Junction Temperature: -40°C to +175°C

• Storage Temperature: -40°C to +150°C

• Package Type: Press-Pack

• Dimensions: 90 × 90 × 28 mm

• Weight: Approx. 600 g

• Mounting Method: Pressure installation (6–8 kN)

• Gate Drive Recommendation: ABB 5STP series gate driver

• Protection Measures: RC snubber circuits, fast fuses, thermistors, or infrared temperature monitoring recommended

Features and Advantages:

1. High Reliability: Weld-free structure and ceramic insulation design for high-temperature, high-load, and long-term operation.

2. Efficient Rectification and Conversion: High-performance semiconductor chips reduce energy loss and improve system efficiency.

3. Modular Design: Easy installation, maintenance, and system upgrades.

4. Excellent Thermal Management: Dual-sided cooling design optimizes heat dissipation.

5. Strong EMI Resistance: Ensures stable power control performance.

6. Wide Compatibility: Seamlessly integrates with ABB medium-voltage drives and industrial power control systems.

Applications:

• Power Transmission: HVDC converters, Flexible AC Transmission Systems (FACTS), Static VAR Compensation (SVC)

• Industrial Applications: High-power motor drives, electrolysis power supplies, induction heating systems

• Renewable Energy: Wind power converters, photovoltaic inverters, energy storage systems

Precautions:

1. Disconnect power before installation or maintenance to prevent electric shock or module damage.

2. Ensure the cooling system is operating correctly to prevent overheating.

3. Avoid prolonged operation in high humidity, dusty, or corrosive environments; use protective measures if necessary.

4. Use anti-static protection when handling or servicing the module.

5. Regularly monitor module temperature and operating status to ensure system safety.

6. Use ABB-certified accessories and cables to ensure system compatibility and reliability.
