ABB 3BHL000986P7000 power supply module

Product Overview:

The ABB 3BHL000986P7000 Power Supply Module is a core power component for ABB medium-voltage drives and industrial automation systems. It provides stable and reliable DC power to control units and power modules. Designed with industrial-grade components, it ensures stable system operation under high load and complex conditions.

Widely used in ABB medium-voltage drives, power converters, industrial automation equipment, and large machinery control systems, it is essential for system safety and high-performance operation.

Technical Specifications:

• Model: 3BHL000986P7000

• Brand: ABB

• Type: Power Supply Module

• Input Voltage: 380–480 V AC, three-phase (system dependent)

• Output Voltage: +24 V DC / +5 V DC (system dependent)

• Rated Output Current: 10–50 A (system dependent)

• Power: 500–1200 W (system dependent)

• Efficiency: ≥ 92%

• Operating Temperature: -20°C to +50°C

• Storage Temperature: -40°C to +70°C

• Humidity: 10%–90% (non-condensing)

• Protection Features: Overvoltage, overcurrent, short circuit, overtemperature

• Mounting: Modular rack or DIN rail

• Cooling Method: Air-cooled

• Compatible Systems: ABB medium-voltage drives, ACS series drives, and industrial automation platforms

Features and Advantages:

1. High Reliability: Industrial-grade design suitable for high temperature, high load, and long-term operation.

2. Stable Output: Provides stable DC power to ensure precise operation of control and power modules.

3. Comprehensive Protection: Built-in overvoltage, overcurrent, short circuit, and overtemperature protection improves system safety.

4. High Efficiency: Reduces energy loss and system heat.

5. Modular Design: Easy installation, maintenance, replacement, and system expansion.

6. Wide Compatibility: Seamlessly integrates with ABB medium-voltage drives and industrial automation systems.

Applications:

• ABB medium-voltage AC drives and control systems

• Industrial automation power and monitoring systems

• Large machinery control units

• Power converters and rectifier systems

• Mining, steel, petrochemical, and high-power industrial equipment

• Renewable energy and energy storage systems

Precautions:

1. Disconnect input power before installation or maintenance to prevent electric shock or module damage.

2. Ensure air-cooling system operates correctly to prevent overheating.

3. Avoid prolonged operation in high humidity, dusty, or corrosive environments; use protective measures if necessary.

4. Use anti-static protection when handling or servicing the module.

5. Regularly check output voltage, current, and temperature to ensure system safety and stability.

6. Use ABB-certified accessories and cables to ensure system compatibility and reliability.
