- ABB 3HAB6249-1 Servo Motor

  1. Product Overview

  The ABB 3HAB6249-1 is an industrial-grade servo motor designed for high-precision motion control systems. It integrates a high-resolution encoder for real-time position feedback, delivering accurate speed, torque, and position control. Compatible with ABB servo drives (e.g., ACS850, MotiFlex e180 series), it suits harsh industrial environments requiring tight motion tolerance, such as robotics, CNC machining, and automated assembly lines.

  2. Technical Specifications

  2.1 Motion Performance
  - Rated Power: 1.5 kW (continuous); 4.5 kW (peak, 10 seconds max)
  - Rated Speed: 3000 rpm (continuous); 4500 rpm (max speed, short-term)
  - Rated Torque: 4.8 N·m (continuous); 14.3 N·m (peak torque)
  - Encoder Resolution: 2048 pulses/revolution (incremental); supports 17-bit absolute feedback (optional)
  - Control Accuracy: Positioning error ≤±0.01 mm (when paired with ABB ACS850 drive; depends on mechanical transmission)
  2.2 Electrical Parameters
  - Supply Voltage: 400 V AC (3-phase, 50/60 Hz)
  - Rated Current: 3.8 A (continuous); 11.4 A (peak)
  - Power Factor: 0.92 (at rated load; high energy efficiency)
  - Insulation Class: Class F (temperature rise ≤105 K; suitable for long-term operation)
  - Protection Class: IP65 (dust-tight, water-resistant; adaptable to dusty/wet industrial sites)
  2.3 Mechanical & Environmental
  - Frame Size: 100 mm (flange diameter; compatible with standard mounting brackets)
  - Shaft Configuration: 19 mm diameter, keyway design (for secure coupling to mechanical loads)
  - Weight: ~8.5 kg (compact for high-power density applications)
  - Operating Temperature: -20°C ~ +40°C (derates 1% per °C above 40°C up to 60°C)
  - Vibration Resistance: 5.9 m/s² (10-2000 Hz; complies with IEC 60034-14)
  3. Application Fields
  - Industrial Robotics: Powers robotic arms (e.g., pick-and-place, welding robots) for precise joint motion and path following
  - CNC Machining: Drives spindle and feed axes of CNC lathes/mills for high-accuracy cutting (e.g., aerospace component manufacturing)
  - Automated Assembly: Controls conveyor positioning and part-handling mechanisms in automotive electronics assembly lines
  - Packaging Machinery: Regulates film unwinding and product indexing in high-speed packaging systems (e.g., food/beverage packaging)
  4. Installation & Maintenance

  4.1 Installation
  - Mount via 100 mm flange (use M6 screws, torque 4.5 N·m); ensure coaxial alignment with load (misalignment ≤0.1 mm to avoid bearing wear)
  - Connect 3-phase power to motor terminals (U/V/W); wire encoder to servo drive (follow ABB pinout diagram for signal integrity)
  - Ground the motor via dedicated terminal (reduces electromagnetic interference; ensures encoder feedback accuracy)
  4.2 Maintenance
  - Check encoder connection quarterly (inspect cable for damage; clean connector pins with dry cloth to prevent signal loss)
  - Lubricate motor bearings annually (use lithium-based grease; follow ABB recommended lubrication amount to avoid over-greasing)
  - Monitor motor temperature during operation (via drive diagnostics; temp >120°C indicates overload or bearing failure)
  - Replace motor if abnormal noise/vibration occurs or encoder feedback fails (avoid disassembling stator/rotor—voids warranty)
