ABB 3BSE052604R1 Analog Input Module

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

1. Product Overview

The ABB 3BSE052604R1 Analog Input Module is a high-reliability analog input module used in ABB Distributed Control Systems (DCS). It is designed to acquire continuous analog signals from field instruments and sensors and convert them into digital values for the control system. The module is suitable for accurate measurement and monitoring of process variables such as pressure, temperature, flow, and level, making it a key I/O component in ABB automation systems.

2. Main Technical Parameters (Typical)

Input Channels

• Number of channels: Multi-channel analog inputs (typically 8 channels)

• Input types:

  • Current signals: 4–20 mA

  • Voltage signals: 0–10 V (configuration dependent)

Measurement Performance

• Resolution: High-resolution A/D conversion (typically 12–16 bit)

• Accuracy: Industrial-grade high accuracy for process control

• Sampling: Periodic multi-channel sampling

Electrical Characteristics

• Channel isolation: Channel or group isolation depending on system design

• Overvoltage and overcurrent protection: Built-in

• Noise immunity: Suitable for harsh industrial environments

Diagnostics

• Input open-circuit detection

• Out-of-range indication

• Internal module self-diagnostics

System Interface

• Directly compatible with ABB controllers and I/O buses

• Hot swap support depending on system architecture

Mechanical and Installation

• Modular plug-in design

• Installation in ABB I/O racks or field control cabinets

Operating Environment

• Industrial operating temperature range

• Designed for continuous operation

3. Advantages and Features

• High-accuracy analog signal acquisition for stable process measurements

• Robust and reliable industrial design

• Comprehensive diagnostics for easier maintenance

• Modular structure enabling fast installation and replacement

• Seamless integration with ABB DCS systems

4. Typical Applications

• Oil and gas process control systems

• Chemical, pharmaceutical, and fine chemical industries

• Power generation and energy systems

• Water and wastewater treatment plants

• Metallurgy, pulp and paper, and cement industries

• General industrial automation and process monitoring

5. Application Notes

• Ensure field instrument signal types match the module input ranges

• Apply proper grounding and shielding to minimize electromagnetic interference

• Perform periodic calibration for high-accuracy applications

• Observe ESD protection when installing or replacing the module

• Follow system procedures if hot swapping is supported
