ABB 3AFE61004955 Output Power Distribution Module

• • • • • 1. Overview

          The ABB 3AFE61004955 Output Power Distribution Module is an industrial-grade power distribution component designed for high-power drive systems and automation equipment.
          It efficiently distributes output power to multiple loads, ensuring stable operation of all submodules. The module follows ABB industrial-grade design standards, offering high reliability, strong interference immunity, and long service life. It is widely used in medium- and high-voltage drives, large industrial drive systems, and automation control systems.

          ---

          2. Key Technical Specifications (Typical)

          Electrical

          • Model: 3AFE61004955

          • Type: Output Power Distribution Module

          • Rated Voltage: 600–690 V AC / DC

          • Rated Current: 100–400 A per output

          • Output Channels: Multiple, configurable per system

          • Short-Circuit Protection: Fast trip and overload protection

          • Insulation Rating: Industrial-grade high insulation

          • Efficiency: > 98%

          Thermal

          • Operating Temperature: –10 °C to +50 °C

          • Storage Temperature: –40 °C to +70 °C

          • Cooling: Air-cooled or external heatsink

          • Overheat Protection: Built-in thermal protection

          Mechanical & Environmental

          • Package: Industrial-grade high-strength structure

          • Mounting: Panel or cabinet installation

          • Protection Rating: IP20

          • Humidity: 5%–95%, non-condensing

          • Vibration Resistance: Industrial-grade

          • Dimensions & Weight: ~450 × 350 × 150 mm, 12–18 kg

          ---

          3. Features & Advantages

          • High reliability for continuous high-load operation

          • Multi-output channels allow flexible power distribution

          • Efficient power distribution with minimal losses

          • Comprehensive protection: overload, short-circuit, overheat

          • Modular design for easy installation, maintenance, and replacement

          • ABB industrial-grade durability for long-term use

          ---

          4. Typical Applications

          • Medium- and high-voltage drive systems

          • High-power drive and industrial automation systems

          • Power transmission and distribution systems

          • Metallurgical and heavy industry equipment

          • Railway traction and power distribution systems

          • Renewable energy power conversion (wind, solar PV)

          • Large UPS systems

          ---

          5. Notes & Precautions

          • Ensure proper contact with cabinet or heatsink and check electrical connections before installation.

          • Avoid exposure to high humidity, dust, or corrosive gases.

          • Keep cooling system operational to prevent overheating.

          • All wiring must be performed with power off.

          • Regularly inspect output terminals and module status for stable power distribution.

          • Avoid frequent large load fluctuations to extend module service life.

        •
