ABB 3ADT209013R0003 Converter

• • • • • 1. Overview

          The ABB 3ADT209013R0003 is a high-performance industrial converter designed for power electronics systems and high-power drive applications.
          It efficiently converts electrical energy between different voltage or current levels and provides a stable output signal. Widely used in DC drive systems, frequency converters, rectifiers, and industrial automation control systems, this converter ensures reliable operation under long-term high-load conditions.

          ---

          2. Key Technical Specifications (Typical)

          Electrical

          • Model: 3ADT209013R0003

          • Type: Power Electronics Converter

          • Input Voltage: 380–690 V AC, three-phase

          • Output Voltage: Adjustable DC output (depending on system)

          • Rated Power: 50–150 kW (typical)

          • Conversion Efficiency: > 95%

          • Output Ripple: < 2%

          • Frequency Range: 50–60 Hz

          • Protection: Overvoltage, overcurrent, short circuit, overtemperature

          Thermal

          • Operating Temperature: –10 °C to +50 °C

          • Storage Temperature: –40 °C to +70 °C

          • Cooling: Air-cooled or external heatsink

          • Thermal Management: Efficient heat dissipation for long-term stability

          Mechanical & Environmental

          • Package: Industrial-grade module

          • Mounting: Panel or cabinet installation

          • Protection Rating: IP20

          • Humidity: 5%–95%, non-condensing

          • Vibration Resistance: Industrial-grade

          • Dimensions & Weight: ~400 × 300 × 150 mm, 10–15 kg

          ---

          3. Features & Advantages

          • High-efficiency energy conversion

          • Industrial-grade reliability for continuous high-load operation

          • Comprehensive protection: overvoltage, overcurrent, short circuit, overtemperature

          • Modular design for easy installation and maintenance

          • Low noise and thermal output with efficient cooling

          • Broad compatibility with various high-power drives and control systems

          ---

          4. Typical Applications

          • Medium- and high-voltage industrial drives

          • DC drives and DC traction systems

          • High-power rectifier and inverter systems

          • Industrial automation control

          • Power transmission and distribution systems

          • Metallurgical and heavy industry high-power equipment

          • Renewable energy conversion: wind and solar PV

          ---

          5. Notes & Precautions



          • Verify input/output terminals before installation; ensure proper insulation.

          • Avoid exposure to high humidity, dust, or corrosive gases.

          • Maintain clear airflow or heatsink for cooling to prevent overheating.

          • All wiring must be performed with power off.

          • Regularly inspect terminals and cooling systems for stable long-term operation.

          • Avoid frequent large load fluctuations to prolong module life.

        •
