ABB 1SFL487002R1300 AF190-30-00-13 three-phase contactor

We will arrange delivery within 3-5 days after receiving the payment.

Our express delivery: DHL and FedEx.

Quality packing for each product

Destination country all taxes & duty to be paid by buyer

Only part of the brand and model, if you have other product needs, please contact us.

ABB 1SFL487002R1300 AF190-30-00-13 Three-Phase Contactor Product Documentation

1. Product Description
The ABB 1SFL487002R1300 AF190-30-00-13 is a three-phase contactor belonging to ABB's AF190 series of industrial-grade contactors. Designed for controlling three-phase motors and power circuits, it offers a high rated operational voltage of up to 1000 V AC, featuring high reliability, long service life, and excellent electrical performance. It utilizes electronic coil control technology, supports a wide range of AC/DC control voltages, and has built-in surge protection, eliminating the need for external suppressors. It is suitable for motor control and protection applications in various global grid conditions and harsh industrial environments.

2. Detailed Parameters

3. Product Advantages and Features
3.1 High Performance and Reliability: Rated current up to 190A and rated power of 90kW, supporting operational voltages up to 1000V AC, suitable for heavy-duty industrial applications. Uses high-quality materials and industrial-grade design to ensure long life and stable operation, with a mechanical life exceeding 1,000,000 operations.
3.2 Wide Voltage Coil Technology: The coil supports a wide range of control voltages (100-250V AC/DC), allowing a few coil types to cover global standard grid voltages, simplifying inventory management and supply chain.
3.3 Energy Efficiency Optimization: Electronic coil interface technology reduces holding energy consumption by up to 80%, helping save energy and lower operating costs.
3.4 Built-in Surge Protection: The contactor has integrated surge protection, eliminating the need for external surge suppression modules, enhancing system reliability and reducing external component requirements.
3.5 Strong Compatibility and Integration: Can be seamlessly integrated with other ABB products (e.g., overload relays, auxiliary contact blocks) to form direct-on-line, reversible, and star-delta starters. Offers various accessory options to enhance system flexibility.
3.6 Voltage Disturbance Immunity: Complies with SEMI F47-0706, withstands short-time voltage dips and interruptions, ensuring continuous operation under unstable grid conditions.

4. Application Fields
4.1 Industrial Motor Control: Used for controlling three-phase motors in factories, such as pumps, fans, compressors, conveyor belts, etc., applicable to manufacturing, petrochemical, mining, and other industries.
4.2 Power Infrastructure: Controls power circuits and distribution systems in power plants and substations, supporting power lines up to 1000V AC.
4.3 Heavy Machinery Equipment: Suitable for motor starting and control in heavy machinery like cranes, rolling mills, crushers, etc..
4.4 Renewable Energy Systems: Used for power control and motor management in wind and solar power plants.
4.5 Building and Infrastructure: Applied in power control and motor management for critical facilities like large buildings, water treatment plants, airports, etc..

5. Precautions
5.1 System Compatibility Verification: Before installation, ensure the contactor's rated voltage and current match the motor load, and verify the coil voltage is compatible with the control supply (100-250V AC/DC).
5.2 Installation and Wiring Specifications:
* Follow the manufacturer's guidelines for proper installation (panel or DIN rail), ensuring sufficient cooling space.
* Use appropriate torque to tighten screw terminals to prevent overheating; main circuit wire sizing must meet rated current requirements.
5.3 Protection and Safety Measures:
* Although the contactor has built-in surge protection, it is still recommended to configure overcurrent protection devices (e.g., circuit breakers or fuses) in the control circuit.
* For applications like reversible starting, ensure the use of mechanical interlock accessories to prevent short circuits.
5.4 Environmental Conditions: Operating temperature -40°C to +70°C; avoid exposure to corrosive gases, excessive dust, or humidity >95%.
5.5 Maintenance and Inspection: Regularly inspect contact wear and connection tightness; utilize ABB diagnostic accessories (e.g., auxiliary contact blocks) for status monitoring.
5.6 Safe Operation: Disconnect power before operation and verify no voltage; for high-inertia loads, consider soft-start or derating measures to reduce arcing erosion.

The structure and details of the product：
