ABB 1SBL141001R8010 3-Pole Contactor

1. Key Parameters

• Product Model: 1SBL141001R8010
• Product Series: ABB Compact 3-Pole AC Contactors (Low-Medium Power Load Switching)
• Core Function: Switches 3-phase AC power to low-medium power loads (e.g., small motors); provides basic arc suppression during contact operation; enables remote control via low-voltage coil signals; supports integration with overload relays for comprehensive motor protection; ensures reliable operation in cyclic switching scenarios
• Electrical & Switching Specifications:

  Parameter	Details	Performance Metrics
  Main Contacts (Power Circuit)	- Configuration: 3 Normally Open (NO) poles (3-phase) - Rated Operational Current (Ie): 10A (AC-3 duty, 400V); 16A (AC-1 duty, resistive loads) - Rated Making Current: 100A (peak, 400V) - Rated Breaking Current: 50A (rms, 400V) - Rated Voltage (Ue): 400V AC (max 690V AC) - Duty Cycle: AC-3 (motor starting/running/stopping—60 starts/hour)	AC-3 duty rating suits 80% of light industrial motor applications; 10A capacity covers small motors up to 4kW (400V)
  Auxiliary Contacts (Control Circuit)	- Configuration: 1 Normally Open (NO) + 1 Normally Closed (NC) (expandable via add-on blocks) - Rated Current: 5A (AC-15, 230V); 2A (DC-13, 24V) - Voltage Rating: 250V AC / 30V DC	Built-in auxiliary contacts simplify basic control logic (e.g., status indicators, interlocks) without additional modules; expandability supports custom circuits
  Coil Specifications	- Voltage Ratings (Selectable): 24V DC, 110V AC, 230V AC - Coil Power Consumption: 5VA (no-load); 30VA (pick-up) - Coil Resistance: 22Ω (24V DC); 1.8kΩ (230V AC) - Dielectric Strength: 2kV AC (coil to frame, 1 minute)	Low no-load power consumption reduces standby energy waste; wide voltage range suits global commercial/industrial electrical systems

• Mechanical & Environmental Specifications:

  Parameter	Details	Performance Metrics
  Mechanical Design	- Dimensions: 45mm (W) × 80mm (H) × 65mm (D) - Mounting Type: 35mm DIN rail (EN 50022) or panel mount (via adapter) - Housing Material: Flame-retardant thermoplastic (UL 94 V0) - Weight: Approximately 180g - Arc Suppression: Built-in arc chutes (plastic material with air gaps)	Ultra-compact 45mm width enables dense mounting (up to 22 units per meter of DIN rail); flame-retardant housing meets commercial safety standards
  Environmental Ratings	- Operating Temperature Range: -25℃~+60℃ (-13℉~140℉) - Storage Temperature Range: -40℃~+85℃ (-40℉~185℉) - Humidity Tolerance: 5%~95% RH (non-condensing, 40℃) - Vibration Resistance: 10~500Hz, 1g acceleration (IEC 60068-2-6) - Shock Resistance: 25g (11ms half-sine, IEC 60068-2-27) - EMC Compliance: EN 61000-6-2 (immunity: Level 2)	Wide temperature range suits unconditioned commercial spaces (e.g., retail storage rooms, office utility closets); vibration tolerance prevents contact chatter near small machinery

• Compliance Standards: CE, UL 508, CSA C22.2 No.14, IEC 60947-4-1, RoHS |

2. Core Features

• Compact 3-Pole Design: 45mm width and 3 normally open poles—fits in space-constrained control cabinets (e.g., commercial HVAC panels, retail display cooler enclosures) and enables efficient 3-phase load control without wasting DIN rail space.
• AC-3 Duty for Motor Control: 10A rated current at 400V (AC-3)—specifically designed for small motor starting, running, and stopping (60 starts/hour), making it ideal for light industrial applications (e.g., 2kW conveyor motors, 3kW pump motors).
• Built-In Auxiliary Contacts: 1NO+1NC contacts (5A AC-15)—supports basic control logic (e.g., "motor running" LEDs, emergency stop interlocks) out of the box; add-on auxiliary blocks (e.g., ABB CA5 series) enable further expansion for complex circuits.
• Global Voltage Compatibility: Coil options for 24V DC, 110V AC, and 230V AC—suits diverse electrical systems (e.g., 230V AC in European offices, 110V AC in North American retail stores, 24V DC in industrial control cabinets), simplifying global inventory management.
• Low Energy Consumption: 5VA no-load coil power—reduces standby energy waste in systems where contactors remain energized for extended periods (e.g., continuous-duty office HVAC fans), lowering operational costs for commercial facilities.
• Flame-Retardant & Durable Housing: UL 94 V0 thermoplastic—meets strict fire safety standards for commercial electrical enclosures; -25℃~+60℃ operating range ensures reliability in unconditioned spaces (e.g., garage workshops, warehouse utility rooms).
• Easy Installation & Wiring: DIN rail mounting and tool-less push-in terminals—enables fast setup (3–5 minutes per unit) by electricians, reducing installation time for light industrial and commercial projects (e.g., office HVAC upgrades).

3. Application Fields

• Commercial Building Automation: HVAC & utility control:
  • HVAC Fans & Pumps: Controls 2kW~4kW 3-phase fan motors (e.g., office air handlers) and pump motors (e.g., boiler circulators)—compact size fits in wall-mounted HVAC control panels; auxiliary contacts integrate with BMS for status monitoring.
  • Retail Refrigeration: Manages 1.5kW~3kW 3-phase compressor motors in display coolers—low no-load power consumption reduces store energy bills; flame-retardant housing meets commercial kitchen safety standards.
• Light Industrial & Manufacturing Auxiliaries: Small machinery control:
  • Mini Conveyors: Controls 1kW~2kW 3-phase conveyor motors in assembly lines—AC-3 duty handles frequent starts/stops; arc suppression ensures reliable operation in dusty factory environments.
  • Packaging Auxiliaries: Switches power to 2kW~3kW 3-phase film unwind motors and label applicators—DIN rail mounting allows grouping with sensors and timers in compact machine cabinets.
• Office & Institutional Facilities: Light-duty equipment control:
  • Data Center Cooling: Controls 3kW~4kW 3-phase server room air conditioner compressors—wide temperature range (-25℃~+60℃) suits equipment rooms; auxiliary contacts trigger "AC on" alerts for facility managers.
  • School & Hospital Utilities: Manages 1.5kW~2.5kW 3-phase water pumps and ventilation fans—manual reset (with optional overload relay) prevents unexpected restart after power outages, enhancing safety.
• Residential & Hobby Applications: Small-scale 3-phase control:
  • Home Workshops: Controls 1kW~2kW 3-phase small lathes and mills—easy toggle operation simplifies use for hobbyists; compact size fits in garage utility panels.
  • Residential Solar Inverters: Switches 3-phase output from small solar inverters (up to 4kW) to home electrical systems—EMC immunity resists interference from inverter electronics; wide voltage range tolerates grid fluctuations.
•
•

The structure and details of the product：
