ABB 07KP60R10 1GJV3074360R101 Communication Module

1. Key Parameters

• Product Model: 07KP60R10 1GJV3074360R101
• Product Series: ABB Industrial High-Speed Communication Modules (Multi-Protocol Gateway & Redundant Network Interface)
• Core Function: Enables data transmission between ABB DCS (e.g., 800xA), PLCs (e.g., AC500), and field devices via 6 industrial protocols; supports dual redundant Ethernet ports for fault-tolerant communication; provides 2kVrms galvanic isolation between networks; integrates real-time traffic monitoring and error logging; enables DIN rail or rack mounting; ensures low-latency (<5ms) data exchange in large-scale automation systems
• Electrical & Communication Specifications:

  Parameter	Details	Performance Metrics
  Protocol Support & Performance	- Supported Protocols: Profinet RT/IRT (1Gbps), EtherNet/IP (100Mbps), Modbus TCP/RTU, IEC 61850 GOOSE/SV, ABB AC 800M Protocol, DNP3.0 - Communication Latency: <5ms (Profinet IRT ↔ EtherNet/IP); <10ms (Modbus RTU ↔ TCP) - Concurrent Connections: Up to 32 simultaneous client/server sessions - Data Throughput: 1Gbps (max, Profinet IRT)	Profinet IRT support enables synchronized motion control (e.g., robotic production lines); IEC 61850 compatibility suits smart grid substation communication; multi-protocol interoperability eliminates "protocol silos" in hybrid automation systems
  Network Interface & Isolation	- Ethernet Ports: 2× Gigabit Ethernet (RJ45, redundant, auto-negotiation) - Serial Ports: 2× RS485 (Modbus RTU/DNP3.0, 9600~115200 bps) - Isolation: 2kVrms galvanic isolation (Ethernet ports to serial ports/power) - EMI Filtering: Built-in industrial-grade EMI/RFI filter (per EN 61000-6-2)	Dual redundant Ethernet ports ensure <100ms failover during network outages; 2kVrms isolation blocks ground loops between field devices and control systems; EMI filtering resists noise from VFDs and high-voltage equipment

• Mechanical & Environmental Specifications:

  Parameter	Details	Performance Metrics
  Mechanical Design	- Dimensions: 130mm (W) × 90mm (H) × 60mm (D) - Mounting Type: 2 options (1) DIN rail mount (EN 50022, 35mm, tool-less snap-on); (2) 19-inch rack mount (via adapter kit 07KP-MNT-001) - Housing Material: Flame-retardant thermoplastic (UL 94 V0) + aluminum shielding frame - Weight: Approximately 520g - Indicators: 2× Ethernet status LEDs (green = link, yellow = activity); 2× serial port LEDs (green = active); 1× power LED (green = 24V DC present); 1× fault LED (red = communication error)	Aluminum shielding frame reduces EMI emission by 40% vs. plastic-only designs; compact form factor fits in dense control cabinets; color-coded LEDs enable quick network status verification (e.g., yellow Ethernet LED = data transmission)
  Environmental Ratings	- Operating Temperature Range: -40℃~+70℃ (-40℉~158℉) - Storage Temperature Range: -55℃~+85℃ (-67℉~185℉) - Humidity Tolerance: 5%~95% RH (non-condensing/condensing, up to 60℃) - Vibration Resistance: 10~500Hz, 2g acceleration (IEC 60068-2-6) - Shock Resistance: 30g (11ms half-sine, IEC 60068-2-27) - EMC Compliance: EN 61000-6-2 (immunity: Level 4); EN 61000-6-3 (emission: Class B)	-40℃~+70℃ range suits extreme environments (arctic pipelines, desert solar farms); condensing humidity tolerance eliminates dehumidifiers in damp areas (e.g., water treatment plants); Level 4 EMC immunity withstands severe industrial noise (welding, high-voltage switchgear)

• Compliance Specifications:

  Parameter	Details	Performance Metrics
  Safety & Compliance	- Safety Standards: CE, UL 508, CSA C22.2 No.14, IEC 61131-2 (industrial communication) - Network Certification: Profinet CERTIFIED, EtherNet/IP Conformance Tested - RoHS Compliance: EU RoHS 2.0 (Restriction of Hazardous Substances)	Profinet/EtherNet/IP certifications ensure interoperability with third-party devices; UL 508 compliance validates safety in North American industrial networks; flame-retardant design reduces fire risk in dense cabinet configurations

2. Core Features

• 6-Protocol Multi-Gateway Functionality: Supports Profinet RT/IRT, EtherNet/IP, Modbus (TCP/RTU), IEC 61850, ABB AC 800M Protocol, and DNP3.0—bridges communication between legacy devices (e.g., Modbus RTU sensors) and modern ABB systems (e.g., 800xA DCS); eliminates the need for multiple single-protocol modules, reducing hardware costs by 30%.
• Dual Redundant Ethernet (1Gbps): Gigabit Ethernet ports with auto-failover (<100ms) ensure uninterrupted communication—critical for mission-critical systems (e.g., power plant turbine controls) where network downtime risks production loss; redundant paths prevent single points of failure in large automation networks.
• 2kVrms Galvanic Isolation: Isolates Ethernet/serial ports from power and ground—blocks ground loops and high-voltage transients (e.g., from lightning strikes in substations), protecting sensitive ABB DCS/PLCs from damage and ensuring signal integrity.
• Low-Latency Real-Time Communication: <5ms latency for Profinet IRT/EtherNet/IP—enables time-sensitive applications (e.g., synchronized robotic assembly lines with 10+ axes); 1Gbps throughput supports large data flows (e.g., video monitoring + sensor data in smart factories).
• Industrial-Grade Durability: UL 94 V0 housing + aluminum shielding + -40℃~+70℃ range—withstands harsh conditions (dust, moisture, temperature extremes) that degrade commercial communication modules; 30g shock resistance survives accidental impacts during plant maintenance, extending service life to 12+ years.
• Integrated Diagnostics & Monitoring: Real-time traffic analysis + error logging + LED status indicators—technicians can quickly identify issues (red fault LED = protocol mismatch, yellow Ethernet LED = no activity) via ABB Automation Builder or at-a-glance LED checks; logs store 1000+ error events for root-cause analysis.
• Seamless ABB System Integration: Optimized for ABB 800xA DCS and AC500 PLCs—pre-configured drivers eliminate custom programming; DIN rail/rack mount options align with ABB cabinet layouts; compatible with ABB network management tools (e.g., System 800xA Network Manager) for centralized monitoring.

3. Application Fields

• Power Generation & Transmission:
  • Thermal Power Plants: Connects turbine control systems (ABB AC800M) to substation protection relays—uses IEC 61850 GOOSE for fast fault signaling; redundant Ethernet ensures no data loss during grid transients; 2kVrms isolation blocks high-voltage interference from generators; -40℃ rating suits outdoor switchyards.
  • Smart Grid Substations (220kV+): Bridges DNP3.0 (SCADA system) to IEC 61850 (protection relays)—transmits real-time voltage/current data with <10ms latency; aluminum shielding resists EMI from high-voltage equipment; redundant ports prevent communication gaps during maintenance.
• Petrochemical & Process Industries:
  • Refinery Distributed Control: Links 800xA DCS to field instruments—converts Profinet (analytical sensors) to Modbus RTU (valve controllers); low latency ensures timely response to process deviations (e.g., pressure spikes); condensing humidity tolerance suits damp reagent storage areas.
  • Chemical Batch Plants: Integrates AC500 PLCs with batch management systems—uses EtherNet/IP for recipe data transmission; real-time monitoring logs track communication errors, enabling predictive maintenance; EMI filtering resists noise from 搅拌 motors.
• Metallurgy & Heavy Manufacturing:
  • Steel Mill Rolling Lines: Synchronizes robotic arms (Profinet IRT) with conveyor controls (EtherNet/IP)—<5ms latency ensures precise material handling; redundant Ethernet prevents production stops from network faults; vibration resistance withstands rolling mill operation.
  • Aluminum Smelters: Connects pot line controls to central DCS—uses Modbus TCP for high-temperature sensor data; 2kVrms isolation protects DCS from pot line electrical noise; high-temperature tolerance (+70℃) suits smelter environments.
• Smart Manufacturing & Logistics:
  • Automotive Body Shops: Links robotic welding cells (Profinet IRT) to MES systems (EtherNet/IP)—1Gbps throughput handles video inspection + sensor data; redundant ports ensure no downtime during network reconfiguration; compact design fits in robotic controller cabinets.
  • Warehouse Automation: Integrates AC500 PLCs (conveyor controls) with WMS systems—converts Modbus RTU (encoder data) to EtherNet/IP; low latency ensures accurate order tracking; DIN rail mount aligns with warehouse control panels.

The structure and details of the product：
