A-B MPL-B330P-SJ74AA Servo Motor

Product Overview
The Allen-Bradley MPL-B330P-SJ74AA is an MP-Series MPL low-inertia brushless AC servo motor designed for high-performance motion-control applications. It features a 460 VAC rating, 5000 RPM speed, single-turn high-resolution encoder, keyed shaft, and integral 24 VDC holding brake.

Technical Specifications

• Model: MPL-B330P-SJ74AA
• Series: MP-Series MPL
• Type: Low-Inertia AC Servo Motor
• Voltage: 460 VAC
• Phase: 3-Phase
• Frame Size: 100 mm
• Magnet Stack Length: 76.2 mm (3.0 in.)
• Rated Speed: 5000 RPM
• Rated Output: Approx. 1.8 kW
• Continuous Stall Torque: 4.18 N·m
• Peak Stall Torque: 11.1 N·m
• Feedback: Single-turn high-resolution encoder
• Encoder: 1024 sin/cos absolute encoder
• Shaft: Keyed shaft, no shaft seal
• Brake: 24 VDC holding brake
• Connector: Right-angle SpeedTEC DIN, 180° rotatable
• Mounting: IEC metric flange
• Rotor Inertia: 0.00012 kg·m²
• Protection: IP66 motor enclosure

Advantages & Features

• Low-inertia design for fast acceleration and deceleration
• High-resolution feedback for precise positioning
• Integrated 24 VDC holding brake
• Compact 100 mm frame
• 5000 RPM high-speed operation
• Brushless permanent-magnet construction
• Right-angle, rotatable SpeedTEC connector for flexible installation

Applications

• Industrial automation
• Packaging machinery
• Material handling
• Electronic assembly
• Automotive manufacturing
• Robotics and precision motion systems
