Allen-Bradley 800T-FXT6A1 Push Button Operator

Product Description

Allen-Bradley 800T-FXT6A1 is a 30 mm push-pull twist release push button operator designed for industrial control panels and machine operator stations. It features a red mushroom head, maintained push-pull operation, and a 1 N.C. + 1 N.O. contact configuration, providing reliable manual control for industrial automation equipment. It is suitable for demanding factory environments requiring durable and dependable operator controls.

Technical Specifications

Advantages & Features

• Durable Industrial Construction
  Designed with rugged materials for reliable operation in industrial environments.
• Push-Pull Twist Release Function
  Provides secure maintained operation, preventing accidental reset during machine operation.
• High Visibility Mushroom Head
  Red emergency-style button design allows quick identification and operation.
• Reliable Contact Performance
  Supports both normally open and normally closed contacts for flexible control circuit applications.
• Standard 30 mm Mounting Design
  Easy integration into industrial control panels and operator stations.
• Long Mechanical Service Life
  Designed for frequent operation with stable switching performance.

Applications

• Industrial Control Panels
• Machine Start/Stop Stations
• Motor Control Systems
• Factory Automation Equipment
• Production Line Control
• Packaging Machinery
• Material Handling Systems
• Industrial Safety Control Circuits

Precautions

• Confirm contact configuration requirements before installation.
• Ensure compatibility with the selected contact blocks and accessories.
• Disconnect power before wiring or maintenance.
• Avoid installation in environments exceeding rated temperature and protection limits.
• Check mounting hole size (30 mm) before replacement.
• Perform operational testing after installation.
