Allen-Bradley 800G-SM3 Push Button Switch Module

Product Description

Allen-Bradley 800G-SM3 is a 30 mm selector switch module designed for industrial control panels and hazardous location applications. It features a 3-position maintained selector switch with neutral position, providing reliable manual control and operator interface functions for industrial automation systems. The module is part of the Allen-Bradley 800G hazardous location push button family and is designed for demanding industrial environments.

Technical Specifications

Advantages & Features

• Durable Industrial Design
  Designed for heavy-duty industrial applications with excellent mechanical durability and long service life.
• 3-Position Control Function
  Provides flexible manual control with three selectable positions for different operating modes.
• Reliable Switching Performance
  Ensures stable operation in industrial control circuits and automation equipment.
• Hazardous Location Capability
  Suitable for demanding environments requiring enhanced protection and reliability.
• Easy Panel Integration
  Standard 30 mm mounting design allows convenient installation in industrial control cabinets.

Applications

• Factory Automation Control Panels
• Industrial Machinery Operation
• Motor Control Systems
• Process Automation Equipment
• Production Line Control Stations
• Oil & Gas Equipment
• Chemical Processing Systems
• Hazardous Area Control Applications

Precautions

• Confirm the correct switch configuration before installation.
• Ensure compatibility with the required contact blocks and accessories.
• Disconnect power before wiring or maintenance.
• Avoid installation in environments beyond the specified protection rating.
• Check operating conditions and temperature requirements before use.
• Ensure proper sealing and mounting to maintain protection performance.
