- - Allen‑Bradley 5094-RTB3I Isolated Remote Terminal Base

    Product Overview

    Screw-type isolated removable terminal base for Flex 5000 distributed I/O modules. It pairs with the 5094-MB mounting base to form a complete terminal assembly (5094-TB3I). Designed for analog I/O modules with channel-to-channel electrical isolation for remote distributed I/O stations.

    Core Specifications

    Terminal style: Screw-clamp, accommodates 22–14 AWG copper wires, tightening torque 3.5 in-lb

    Electrical isolation: 250 VAC isolation between channels and between channels to ground to suppress signal interference

    Per-channel current rating: 2 A @ 32 VDC; total field power supply rating 10 A (18–32 VDC)

    Operating environment: -40℃ to 70℃, IP20 cabinet mounting, UL, CE, ATEX Zone 2 certified

    RIUP hot-swap capability: I/O modules can be replaced without disconnecting field wiring

    Dimensions: 54.9 × 93.6 × 76.4 mm, net weight approx. 288 g

    Compatibility: 5094 series isolated analog modules (5094-IF8IH, 5094-OF8IH, etc.) and digital I/O modules

    Main Functions

    Centralize analog signals from field sensors and control valves with independent channel isolation

    Split modular design separates terminal base from I/O module, retaining all field wiring during maintenance

    Deliver 24 VDC power to field transmitters for stable remote analog signal acquisition and output

    Keyed anti-mismatch structure to prevent incorrect installation of different terminal base models

    Key Advantages

    Compared with the non-isolated 5094-RTB3, full-channel isolation greatly improves anti-interference performance for analog signals. Screw terminals deliver reliable connections for long industrial cables. Hot-swap function minimizes downtime during maintenance. Hazardous area certifications support chemical, oil and gas applications.

    Typical Applications

    Process control remote analog input stations, distributed I/O for water treatment and metallurgy, signal cabinets for oil & gas hazardous locations, high-precision temperature/pressure control loops, isolated analog automation production line systems
