Allen‑Bradley 5069-RTB18-SCREW Removable Screw Terminal Base Assembly

Product Overview

Core Specifications

Wiring Parameters

• Terminal type: Screw-clamp terminal, recommended torque 0.4 N·m (3.5 lbf·in)Rockwell Automation
• Wire gauge range: 0.5–1.5 mm² / 22–16 AWG solid/stranded shielded copper wire (105°C rated)
• Max wire outer diameter (with insulation): 3.5 mm
• Required wire stripping length: 12 mmRockwell Automation
• Single wire connection only per terminal point

Mechanical & Dimension

• Total pin count: 18 signal terminals
• Overall size: 138 mm × 22 mm × 105 mm (L×W×D)
• Housing material: Flame-retardant gray industrial plastic
• Locking latch: Side snap lock for fast plug/unplug with I/O modules
• Weight: ~0.12 kg

Environmental & Electrical Rating

• Operating temperature: 0 ℃ ~ +60 ℃
• Storage temperature: -40 ℃ ~ +85 ℃
• Humidity: 5%–95% non-condensing
• Voltage rating: 250 VAC continuous, basic insulation
• Protection class: IP20 (indoor cabinet installation only)
• Certifications: UL, cUL, CE, CCC, Class I Div 2 hazardous location compliant

Compatible I/O Modules

Main Functions

1. Field Wiring Connection Carrier

   Centralize all sensor, actuator, valve, relay field wires onto unified screw terminals, orderly wiring layout for cabinet maintenance.
2. Detachable Split Wiring Design

   The terminal base can be unplugged from the I/O module independently. When replacing faulty I/O modules, no need to disconnect field cables, greatly shortening downtime.
3. Vibration-resistant Screw Clamping

   Screw fastening eliminates loose wire risks caused by equipment vibration, far more stable than spring terminals for heavy machinery, metallurgy and mining environments.
4. Standardized Signal Routing

   Correspond 18 wiring terminals one-to-one with I/O module internal channels, standard pin definition consistent across all matched 5069 I/O modules.
5. Overcurrent & Insulation Protection

   Flame-retardant plastic housing prevents fire spread from short-circuit faults; reinforced insulation isolates field signals from PLC backplane power circuits.
6. Quick On-site Troubleshooting

   Detachable terminal base allows offline continuity testing of field sensors and actuators without powering off the PLC rack.

Key Advantages

• Screw terminal structure offers superior anti-vibration performance, ideal for stamping, metal processing, heavy conveyor equipment
• Fully detachable design realizes hot-swap I/O maintenance without re-terminating field cables
• Universal 18-pin specification compatible with most Compact 5000 I/O modules, unified spare parts management
• Clear pin marking printed on housing, convenient for wiring verification and fault inspection
• Flame-retardant high-temperature plastic housing adapts to high-temperature enclosed control cabinets
• Alternative spring-clamp version (5069-RTB18-SPRING) available for quick wiring scenarios
