Allen‑Bradley 5069-L340ERM CompactLogix 5380 Integrated Motion Controller

Product Overview

Core Technical Specifications

Performance & Memory

• User application memory: 4 MB
• Max local Compact 5000 I/O modules: 31
• Max EtherNet/IP network connected nodes: 90
• Integrated CIP motion axes limit: 20 closed-loop position axes (Kinetix 5500/6500/5700 drives)
• Processor: Quad-core high-speed architecture for fast logic scans and motion loop refresh
• Task scheduling: Up to 32 continuous/periodic/event tasks
• Non-volatile storage: SD card slot compatible with 1784-SD1/SD2 industrial memory cards for program backup, firmware storage and production data logging

Communication Interfaces

• Dual 10/100/1000 Mbps Gigabit EtherNet/IP RJ45 ports
  • Supported topologies: DLR Device Level Ring, Linear, Star, Dual-IP network isolation
  • Transmits real-time motion commands, I/O data, CIP safety signals and HMI communication simultaneously
• USB 2.0 Type‑B port: Temporary offline programming, firmware upgrade and online debugging (not for permanent field wiring)
• Isolation rating: 300 V continuous insulation between Ethernet circuits and backplane DC power; no isolation between the two Ethernet portsRockwell Automation

Electrical Power Ratings

• MOD logic input power: 18–32 VDC, rated 450 mA, peak inrush 850 mA (125 ms duration)
• SA universal auxiliary power input: 0–32 VDC / 0–240 VAC 47–63 Hz
• Maximum power dissipation: 8.5 W (29 BTU/hr)
• Standard supercapacitor short-term memory backup; -NSE suffix removes supercap backup function

Mechanical & Environmental Parameters

• Mounting: Horizontal installation only on standard 35 mm DIN rail (EN50022)
• Overall dimensions (H×W×D): 143.97 × 98.10 × 136.81 mm
• Net weight: ~0.768 kg (1.693 lb)
• Enclosure rating: IP20, for indoor control cabinet installation only
• Operating temperature: 0 °C ~ +60 °C; storage temperature: -40 °C ~ +85 °C
• Relative humidity: 5%–95% non‑condensing
• Shock & vibration: Compliant with IEC 60068 industrial mechanical test standards
• Front panel multi-color LEDs: Run/Fault status, Ethernet link/activity, backplane module error indicators

Global Certifications

Main Functions

1. Integrated EtherNet/IP CIP Motion Control



   Native motion processor executes high-speed closed-loop position/velocity/torque control for up to 20 servo axes via EtherNet/IP. Supports electronic gearing, cam profiling, multi-axis linear/circular interpolation, gantry synchronization and flying shear cutting without separate motion modules. Seamlessly pairs with all Kinetix series servo drives and MPL/MPM servo motors for unified motion programming in Studio 5000 Logix Designer.
2. Complex Discrete & Analog Logic Execution



   Supports Ladder Diagram, Function Block Diagram, Structured Text and Sequential Function Chart programming languages to control local Compact 5000 digital/analog I/O and distributed remote field devices, handling complex machine interlocks, batch sequencing and PID process regulation alongside motion tasks.
3. Dual Gigabit EtherNet/IP Redundant Network Gateway

• Dual‑IP mode physically separates OT control network and IT enterprise network without external switches
• DLR ring topology provides single cable break redundancy to avoid unplanned production downtime
• Simultaneously transmits real-time motion commands, safety signals, HMI screen data and fault alarm logs across the factory network

4. Comprehensive System Diagnostics & Fault Logging



   Front-panel LEDs deliver instant visual health status; detailed motion axis faults, I/O module failures and network error codes are stored in controller event logs and uploaded to HMI for remote troubleshooting and equipment maintenance traceability.
5. Built‑in Industrial Cybersecurity Suite

• Encrypted, digitally signed firmware to prevent unauthorized tampering
• Role‑based access control for program editing and online modification
• Full operation change logging and unauthorized access detection
• Configurable network security policies to isolate control networks from office IT infrastructure

6. Offline Program Backup & Rapid System Recovery



   SD card slot stores complete controller logic, motion axis configuration, tag database and firmware files. When replacing a failed controller, the unit auto-restores all motion and control programs without re-downloading from a programming workstation, drastically cutting downtime.
7. Large‑Scale Distributed Remote I/O Management



   Drives up to 31 local Compact 5000 I/O modules and remote EtherNet/IP I/O racks, shortening long-distance field wiring and reducing electromagnetic interference for scattered production stations and process skids.

Key Advantages

• Dedicated motion processing core delivers ultra-fast motion loop refresh, eliminating lag for high‑speed reciprocating, cutting and packaging equipment
• 20-axis motion capacity covers medium multi-axis machines without extra motion cards, saving cabinet space and hardware cost
• Quad-core high-speed processor outperforms legacy 1769 CompactLogix controllers for mixed logic + motion heavy workloads
• Dual integrated 1 Gbps Ethernet ports eliminate external switches for network isolation or DLR ring redundancy
• Unified Studio 5000 programming environment shares identical motion instruction sets with ControlLogix large PLC platforms for seamless project migration
• Wide hazardous location certification supports chemical, water treatment and light petrochemical cabinet deployments
• Highly modular expandable local I/O rack, flexible to add analog, temperature, relay and safety I/O modules on-site
• Complete native security functionality meets modern factory IT/OT convergence compliance requirements
