A-B 5069-L340ER CompactLogix 5380 Controller

A-B 5069-L340ER CompactLogix 5380 Controller

The Allen-Bradley 5069-L340ER is a CompactLogix 5380 Ethernet controller with 4 MB user memory, support for up to 31 local Compact 5000 I/O modules and up to 90 EtherNet/IP devices. It is the standard controller version; unlike the 5069-L340ERM, it does not provide integrated motion.

Key Technical Specifications

Rockwell specifically identifies the 5069-L340ER as a 4 MB CompactLogix 5380 controller and lists two 1 Gb Ethernet ports, 18–32 VDC MOD power, and a quad-core processor.

Advantages & Features

• 4 MB user memory for larger control applications
• Two integrated 1 Gb EtherNet/IP ports
• Supports up to 31 local Compact 5000 I/O modules
• Supports up to 90 EtherNet/IP devices
• Dual-IP or Linear/DLR network configurations
• Integrated USB programming connection
• Advanced diagnostics and controller status/fault indication
• Supports optional SD-card nonvolatile memory
• Designed for high-performance industrial automation applications

Typical Applications

• Factory automation
• Machine control
• Material handling
• Packaging machinery
• Process control
• Conveyor systems
• Distributed EtherNet/IP control systems
